28 MicroLogix 1400 Programmable Controllers
Publication 1766-IN001D-EN-P - June 2015
Analog Outputs
Description 1766-L32AWAA, -L32BWAA, -L32BXBA
Number of inputs 2 single-ended
Voltage output range 0…10 V DC - 1 LSB
Type of data 12 bit unsigned integer
Step response 2.5 ms @ 95%
Load range
Voltage output 1 KΩ
Output resolution 12 bit
Analog output setting time 3 ms (max.)
Overall Accuracy
-20…60 °C (-4…140 °F)
±1.0% of full scale
Electrical isolation Non-isolated with internal logic
Cable length 30 m (98 ft) shielded cable
Relay and FET Outputs
Description 1766-L32AWA, 1766-L32AWAA,
1766-L32BWA, 1766-L32BWAA
1766-L32BXB,
1766-L32BXBA
Maximum controlled load 1440 VA 1080 VA
Maximum Continuous Current:
Current per channel and group common 2.5 A per channel
8A max channel 8…11 common
2.5 A per channel
Current per controller at 150V max 28 A or total of per-point loads,
whichever is less
at 240V max 20 A or total of per-point loads,
whichever is less
Relay Outputs
Description 1766-L32AWA, 1766-L32AWAA, 1766-L32BWA,
1766-L32BWAA, 1766-L32BXB, 1766-L32BXBA
Turn On Time/Turn Off Time
10 ms (maximum)
(1)
Load current 10 mA (minimum)
(1)
Scan time dependent
