26 MicroLogix 1400 Programmable Controllers
Publication 1766-IN001D-EN-P - June 2015
Specifications
General Specifications
Description 1766-L32AWA
1766-L32AWAA
1766-L32BWA
1766-L32BWAA
1766-L32BXB
1766-L32BXBA
Dimensions
HxWxD
90 x 180 x 87 mm
3.5 x 7.087 x 3.43 in.
Shipping weight 0.9 kg (2.0 lbs)
Number of I/O 24 inputs (20 digital and 4 analog) and 14 outputs (12 digital and 2 analog)
Power supply voltage 100…240V AC (-15%, +10%) @ 47…63 Hz 24V DC (-15%, +10%) Class
2 SELV
Heat dissipation Refer to the MicroLogix 1400 Programmable Controllers User Manual,
Publication 1766-UM001
.
Power supply inrush
current
120V AC: 25 A for 8 ms
240V AC: 40A for 4 ms
24V DC:
15 A for 20 ms
Power consumption 100 VA 120 VA 50W
7.5W (with no 1762
expansion I/O)
24V DC sensor power none 24V DC @ 250 mA
400 µF max.
none
Input circuit type Digital: 120V AC
Analog: 0…10V DC
Digital: 24V DC
sink/source
(standard and high-speed)
Analog: 0…10V DC
Digital: 24V DC
sink/source
(standard and high-speed)
Analog: 0…10V DC
Output circuit type Relay Relay/FET
Relay life - Electrical Refer to Relay Life Chart
Relay life - Mechanical 20,000,000 cycles
Enclosure type rating None (open-style)
Wire size
0.25… 2.5 mm
2
(22…14 AWG) solid or stranded copper wire rated @ 90 °C
(194 °F) or greater.
Wiring category
(1)
(1)
Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and
Grounding Guidelines, publication 1770-4.1
.
2 - on signal ports
2 - on power ports
3 - on communications ports
Terminal screw torque 0.79 Nm (7.0 in-lb) rated
Pilot duty rating C300, R300
Expansion bus Supports up to seven 1762 modules, up to a maximum of 5V, 1500 mA and 24 V,
1500 mA.
North American temp code T3C
