Programming and Parameters 3-25
A111 [0-10V Analog Input High] Related Parameter(s): d020, P035, P038
Sets the analog input level that corresponds to P035 [Maximum Freq] if a 0-10V input is used by P038
[Speed Reference].
Analog inversion can be accomplished by setting this value smaller than A110 [0-10V Analog Input
Low].
Values Default 100.0%
Min/Max: 0.0/100.0%
Display: 0.1%
A112 [4-20mA Analog Input Low] Related Parameter(s): d021, P034, P038
Sets the analog input level that corresponds to P034 [Minimum Freq] if a 4-20mA input is used by
P038 [Speed Reference].
Analog inversion can be accomplished by setting this value larger than A113 [4-20mA Analog Input
High].
Values Default 0.0%
Min/Max: 0.0/100.0%
Display: 0.1%
A113 [4-20mA Analog Input High] Related Parameter(s): d021, P035, P038
Sets the analog input level that corresponds to P035 [Maximum Freq] if a 4-20mA input is used by
P038 [Speed Reference].
Analog inversion can be accomplished by setting this value smaller than A112 [4-20mA Analog Input
Low].
Values Default 100.0%
Min/Max: 0.0/100.0%
Display: 0.1%
A114 [Slip Compensation]
Related Parameter(s): P033
Compensates for the inherent slip in an induction motor. This frequency is added to the commanded
output frequency based on motor current.
Values Default 2.0 Hz
Min/Max: 0.0/10.0 Hz
Display: 0.1 Hz
