Rockwell Automation Allen-Bradley 9000 Series User Manual

2 Rockwell Automation Publication 42G-TD001C-EN-P - June 2022
Series 9000 Photoelectric Sensors Specifications Technical Data
Specifications
Optical and Response Time Characteristics
Table 1 - All Models
Attribute Value
Certifications
cULus Listed, CSA Certified, and CE Marked for all applicable
directives
Shock 30 g with 1 ms pulse duration, meets or exceeds IEC 60947-5-2
Vibration 10…55 Hz, 1 mm amplitude, meets or exceeds IEC 60947-5-2
Environmental
Enclosure type rating IP69K, IP67 with 1200 psi; NEMA 3, 4X, 6P, 12, 13; ECOLAB rated
Relative humidity 5…95%
Ambient light immunity Incandescent light 5000 lux
Electrical
Operating voltage See Table 6 on page 3
.
Mechanical
Material
•Housing: Valox®
•Lens: Acrylic
Connection type
See Table 6 on page 3.
Table 2 - Standard Models
Attribute Value
Environmental
Operating temperature -34…+70 °C (-29…+158 °F)
User Interface
Status indicator See Table 8 on page 5
.
Electrical
Current consumption 30 mA max
Protection type
• Short circuit
• Reverse polarity
•False pulse
•Overload
Outputs
Output type
See Table 6 on page 3.
Output function Selectable light or dark operate
Load current
• 250 mA at 30V DC (all models except 42GLP and 42GSP)
• 2 A at 132V AC and 1 A at 264V AC (SPDT relay models)
• 300 mA at 264V AC (MOSFET models)
Table 3 - Laser Models
Attribute Value
Environmental
Operating temperature -10…+50 °C (-14…+122 °F)
Electrical
Current consumption,
max
• DC models: 45 mA
• AC/DC models: 10 mA
• AC models: 70 mA
Protection type
• Overload and short circuit (DC models)
•Reverse polarity
•False pulse
Outputs
Output type
See Table 6 on page 3.
Output function Selectable light or dark operate
Leakage current, max 10 µA (DC models)
Table 4 - Optical and Response Time Characteristics—Standard and I ntrinsically Safe Transmitted Beam Models
Attribute
Sensing Mode
Retroreflective
Polarized
Retroreflective
Diffuse Transmitted Beam
Small Aperture
Fiber Optic
Large Aperture
Fiber Optic
Field of view 1.5°
3.5° for 1.5 m (4.92 ft)
6.5° for 3 m (9.8 ft) and 4 m (13 ft) range
1.5° Depends on fiber-optic cable
Light source
Visible red 660 nm Infrared 880 nm
Response time 2 ms (DC), SPDT EM relay (15 ms), 2 ms (MOSFET AC/DC)
Table 5 - Optical and Response Time Characteristics—Laser Models
Attribute
Sensing Mode
Polarized Retroreflective Diffuse
Spot size 20 x 25 mm (0.98 in.) at 40 m (131.23 ft) 2 x 3.5 mm (0.14 in.) at 800 nm
Response time 0.5 ms
