Rockwell Automation Allen-Bradley 9000 Series - Approximate Dimensions

Rockwell Automation Publication 42G-TD001C-EN-P - June 2022 7
Series 9000 Photoelectric Sensors Specifications Technical Data
Approximate Dimensions
Dimensions are shown in mm (in.). Dimensions are not intended to be used for installation purposes.
Figure 2 - All Versions (Except Fiber Optic) — Cable Version
Figure 3 - Fiber-optic Versions — Cable Version
Figure 4 - ClearSight™ 9000 Sensor — Cable Version
Figure 5 - Connector Version
M30 x 1.5
External Thread
1/2 in. NPSM
Internal Thread
32.66
(1.286)
16.76
(0.660)
2.0 m (6.5 ft)
Cable Length
6.5 (0.255/0.245) dia.
74.93
(2.950)
69.85
(2.750)
55.62
(2.190)
31.75 (1.250)
103.63
(4.080)
Max Travel
40.00
(1.575)
20.98
(0.825)
15.24
(0.600)
7.62
(0.300)
41.91
(1.650)
30.35
(1.195)
24.69
(0.970)
5.21 (0.205) x
8.13 (0.320)
Slot, 2 Places
15.87 (0.625)
5.46 (0.215)
27.05
(1.065)
42.41 (1.670)
47.75
(1.880)
M30 x 1.5
External Thread
1/2 in. NPSM
Internal Thread
103.63
(4.080)
Max Travel
2.0 m (6.5 ft) Cable Length
6.47/6.22 (0.255/0.245) dia.
5.21 (0.205) x
8.13 (0.320)
Slot, 2 Places
M30 x 1.5
External Thread
1/2 in. NPSM
Internal Thread
32.66
(1.286)
2.0 m (6.5 ft.)
Cable Length
6.47/6.22
(0.25/0.24) dia.
13.33
(0.52)
6.12
(0.24)
40.00
(1.575)
16.76 (0.66)
55.62
(2.190)
103.63
(4.080)
Max Travel
31.75 (1.250)
69.85
(2.750)
74.93
(2.950)
30.35
(1.19)
24.64
(0.97)
5.21 (0.20) x
8.13 (0.32)
Slots, 2 Places
15.24
(0.60)
7.62
(0.30)
20.96
(0.82)
27.05
(1.06)
5.46
(0.21)
15.87
(0.62)
Mounting
Hole
Centerline
41.91
(1.65)
42.42
(1.67)
47.75
(1.88)
103.63
(4.080)
Max Travel
M30 x 1.5 External
Thread 1/2 in. NPSM
Internal Thread
2.0 m (6.5 ft)
Cable Length
6.47/6.22 (0.255/
0.245) dia.
5.21 (0.205) x
8.13 (0.320)
Slot, 2 Places
Mounting
Hole
Centerline
Table 9 - Thread Sizes
Style AC DC
Micro
1/2-20 UNF
2 keyways
M12 x 1
1 keyway
Mini
7/8-16 UN
1 keyway
97
(3.8)
32.89
(1.295)
Cable Length
2 m (6.5 ft)
6.47/6.22
(0.255/0.245) Dia.
39.50
(1.555)
65.23 (2.568)
100.60 (3.961)
Max. Travel
120°
M30 x 1.5 External
Thread 1/2 in. NPSM
Internal Thread
25.1
(0.99)
68.07
(2.68)
}
42.41
(1.670)
41.91
(1.65)
15.87 (0.625)
47.88
(1.885)
5.46 (0.215)
5.21 (0.205) x
8.13 (0.320)
Slot, 2 Plcs.
24.64 (0.970)
30.35 (1.195)
Centerline of Slots
13.41 (0.528)
20.96 (0.825)
Top View
100.60 (3.961)
Max Travel
Top View
Centerline of Slots
5.21 (0.205) x
8.13 (0.320)
Slot, 2 Places
M30 x 1.5 External
Thread 1/2 in. NPSM
Internal Thread
Cable Length 2 m (6.5 ft)
6.47/6.22 (0.255/0.245) Dia.
13.97 (0.550)
17.78 (0.700)
Micro Style Mini Style
Micro Style
Mini Style
