3-16 Programming and Parameters
Advanced Program Group (continued)
A069 [Internal Freq]
Related Parameter(s): P038
Provides the frequency command to the drive when P038 [Speed Reference] is set to 1 “Internal
Freq”. When enabled, this parameter will change the frequency command in “real time” using the
integral keypad Up Arrow or Down Arrow when in program mode.
Important: Once the desired command frequency is reached, the Enter key must be pressed to store
this value to EEPROM memory. If the ESC key is used before the Enter key, the frequency will return
to the original value following the normal accel/decel curve.
Values Default 60.0 Hz
Min/Max: 0.0/240.0 Hz
Display: 0.1 Hz
A070 [Preset Freq 0]
(1)
A071 [Preset Freq 1]
A072 [Preset Freq 2]
A073 [Preset Freq 3]
Related Parameter(s): P038, A051, A052
Provides a fixed frequency command value when A051 - A052 [Digital Inx Sel] is set to 4 “Preset
Frequencies”.
(1)
To activate A070 [Preset Freq 0] set P038 [Speed Reference] to option 4 “Preset Freq 0-3”.
Values A070 Default
A071 Default
A072 Default
A073 Default
0.0 Hz
5.0 Hz
10.0 Hz
20.0 Hz
Min/Max: 0.0/240.0 Hz
Display: 0.1 Hz
Input State of Digital In 1
(I/O Terminal 05)
Input State of Digital In 2
(I/O Terminal 06) Frequency Source Accel / Decel Parameter Used
(2)
0 0 A070 [Preset Freq 0] [Accel Time 1] / [Decel Time 1]
1 0 A071 [Preset Freq 1] [Accel Time 1] / [Decel Time 1]
0 1 A072 [Preset Freq 2] [Accel Time 2] / [Decel Time 2]
1 1 A073 [Preset Freq 3] [Accel Time 2] / [Decel Time 2]
(2)
When a Digital Input is set to “Accel 2 & Decel 2”, and the input is active, that input overrides the settings in
this table.
A078 [Jog Frequency]
Related Parameter(s): P035, A051, A052
Sets the output frequency when a jog command is issued.
Values Default 10.0 Hz
Min/Max: 0.0/P035 [Maximum Freq]
Display: 0.1 Hz
userman.book Page 16 Friday, June 21, 2002 2:48 PM
