B-2 Accessories and Dimensions
Table B.C Dynamic Brake Modules
Table B.D Bulletin 1321-3R Series Line Reactors
Drive Ratings
Catalog NumberInput Voltage kW HP
120V 50/60 Hz
1-Phase
0.2 0.25
(1)
(1)
Drive does not support dynamic braking.
0.37 0.5
(1)
0.75 1.0 160-BMA1
240V 50/60 Hz
1-Phase
0.2 0.25
(1)
0.37 0.5
(1)
0.75 1.0 160-BMA1
1.5 2.0 160-BMA2
240V 50/60 Hz
3-Phase
0.2 0.25
(1)
0.37 0.5
(1)
0.75 1.0 160-BMA1
1.5 2.0 160-BMA2
2.2 3.0 160-BMA2
3.7 5.0 160-BMA2
(2)
(2)
Two in parallel required.
480V 50/60 Hz
3-Phase
0.37 0.5
(1)
0.75 1.0 160-BMB1
1.5 2.0 160-BMB2
2.2 3.0 160-BMB2
3.7 5.0 160-BMB2
(2)
Input Voltage kW HP
Fundamental
Amps
Maximum
Continuous
Amps Inductance
Watts
Loss
Catalog
Number
(1)
(1)
Catalog numbers listed are for 3% impedance open style units. NEMA Type 1 and 5% impedance
reactor types are also available. Refer to publication 1321-TD001x.
240V 50/60 Hz
3-Phase
0.2 0.25 2 3 12.0 mh 7.5 W 1321-3R2-A
0.37 0.5 4 6 12.0 mh 21 W 1321-3R4-D
0.75 1.0 4 6 3.0 mh 14.5 W 1321-3R4-A
1.5 2.0 8 12 1.5 mh 19.5 W 1321-3R8-A
2.2 3.0 12 18 1.25 mh 26 W 1321-3R12-A
3.7 5.0 18 27 0.8 mh 36 W 1321-3R18-A
480V 50/60 Hz
3-Phase
0.37 0.5 2 3 20.0 mh 11.3 W 1321-3R2-B
0.75 1.0 2 3 12.0 mh 7.5 W 1321-3R2-A
1.5 2.0 4 6 6.5 mh 20 W 1321-3R4-B
2.2 3.0 8 12 12.0 mh 25.3 W 1321-3R8-C
3.7 5.0 18 27 3.0 mh 29 W 1321-3R8-B
