B-4 Accessories and Dimensions
PowerFlex 40 Adjustable Frequency AC Drive FRN 1.xx - 7.xx User Manual
Publication 22B-UM001I-EN-E
Table B.F EMC Line Filters
Drive Ratings
S Type Filter
Catalog Number
(1)
(1)
This filter is suitable for use with a cable length of at least 10 meters (33 feet) for Class A and 1
meter for Class B environments.
L Type Filter
Catalog Number
(4)
(4)
This filter is suitable for use with a cable length of at least 100 meters for Class A and 5 meters for
Class B environments.
Input Voltage kW HP
120V 50/60 Hz
1-Phase
0.4 0.5 – 22-RF018-BL
0.75 1.0 – 22-RF018-BL
1.1 1.5 – 22-RF018-BL
240V 50/60 Hz
1-Phase
0.4 0.5
(2)
(2)
These ratings can be ordered with internal “S Type” filters. Refer to the Catalog Number
explanation on page P-4
and Table B.B for details.
22-RF018-BL
0.75 1.0
(2)
22-RF018-BL
1.5 2.0
(2)
22-RF018-BL
2.2 3.0
(2)
22-RF025-CL
240V 50/60 Hz
3-Phase
0.4 0.5 22-RF021-BS
(3)
(3)
Filter must be Series B or later.
22-RF021-BL
0.75 1.0 22-RF021-BS
(3)
22-RF021-BL
1.5 2.0 22-RF021-BS
(3)
22-RF021-BL
2.2 3.0 22-RF021-BS
(3)
22-RF021-BL
3.7 5.0 22-RF021-BS
(3)
22-RF021-BL
5.5 7.5 22-RF034-CS 22-RF034-CL
7.5 10.0 22-RF034-CS 22-RF034-CL
480V 50/60 Hz
3-Phase
0.4 0.5 22-RF012-BS 22-RF012-BL
0.75 1.0 22-RF012-BS 22-RF012-BL
1.5 2.0 22-RF012-BS 22-RF012-BL
2.2 3.0 22-RF012-BS 22-RF012-BL
4.0 5.0 22-RF012-BS 22-RF012-BL
5.5 7.5 22-RF018-CS 22-RF018-CL
7.5 10.0 22-RF018-CS 22-RF018-CL
11.0 15.0 22-RF026-CS 22-RF026-CL
600V 50/60 Hz
3-Phase
0.75 1.0 – 22-RF8P0-BL
1.5 2.0 – 22-RF8P0-BL
2.2 3.0 – 22-RF8P0-BL
4.0 5.0 – 22-RF8P0-BL
5.5 7.5 – 22-RF015-CL
7.5 10.0 – 22-RF015-CL
11.0 15.0 – 22-RF024-CL
22B-UM001.book Page 4 Tuesday, May 30, 2017 5:22 PM
