Page 17 of 17 Tech Note for PSA 2012-01-001 PF7000_GEN-95
B) PanelView CE (VersaView) Terminal
In order to access the required parameters 299 and 780 you will need to place these two parameters in the ‘Display
Custom’ screen and access the parameters from this location.
From the MainMenu, press ‘Display’ and then ‘Custom’ and enter the parameter numbers 691 and 921 into the ‘Display
Custom’ list. You will then be able to access both parameters from this list.
For detailed instructions on accessing the Terminal screens and resetting the faults or warnings and clearing the Alarm or
Fault queues, refer to Classic User Manual – Operator Interface chapter (Chapter 3).
COMPONENT AFFECTED:
Line Filter Capacitor
PRODUCT AFFECTED:
PF7000 Classic VFD (7000A, 7000B, 7000L) with AFE rectifier.
REQUIRED FIELD ACTION:
It is mandatory that the Firmware in all medium voltage PF7000 drives with Classic Control platform be upgraded to the latest
version, 6.002 or higher. After upgrading the Firmware, the copy of latest drive settings must be sent to MV Tech Support by
e-mail at MVSupport_Technical@ra.rockwell.com for our record and future reference.
DOCUMENT REVISION HISTORY:
Date Revision Author Description
January 28, 2010 1.0 Manzoor Memon Original document
April 27, 2010 2.0 Carlos Siri Review Reloading Parameters, Testing Filter
Capacitors and Appendix A
May 3, 2010 3.0 Fred Jason Corrected PSA and documentation
references. Edited for clarity and
consistency.
Dec 06, 2010 4.0 Manzoor Memon Revised the tech note per the requirements of
Firmware 5.009
May 02, 2011 5.0 Najeeb Bohio Revised the Tech note per the
requirement of Firmware 5.010
March 2, 2012 6.0 Carlos Siri Revised the Tech Note per the requirement of
Firmware 6.002
March 5, 2012 6.0 Fred Jason Edits as needed
