About the Drive
2-9
Figure 2.5 – LiquiFlo Regulator Board Component Locations
USER I/O TERMINAL STRIP
34-Pin Ribbon Cable
J8
J17
J4
60-Pin Ribbon Cable
J16
J9
J3
J3 - Option Board Connector
J4 - Analog Input Jumper
J7 - OIM (Optional) Connector
J8 - RS-232C Port
J9 - Keypad/Display Connector
J16 - Power Module Feedback Cable
J17 - Analog Output Jumper
USER DISPLAY
J7
