4-4
LiquiFlo AC Power Modules, Hardware Reference Version 6.4
Figure 4.2 – Wire Routing Locations for C-Frame LiquiFlo Drives
User
Connections
Coolant
Connections
Drive
Input
Wiring
Drive
Output
Wiring
To Motor
(3 Places)
