8
Depress STOP and GO key simultaneously until a rPset is initiated
STOP key to disconnect track power
input address 80
Depress Direction reversing constantly, then ad( lltionally Go for min. 0.5 sec. to reconnect
trackpower
Decoder is in programming mode = flashing of the l ocom otive lights: · · · · · ·
input of
the register to be changed (2 digits) (Two-fi q rre in the address field)
Press Direction Reversing to confirm =double flashi nq: .. .. _ .. ~ · _ :..:__:_: ____ .
input
selected value (Two-figure in the address field)
Press Direction Reversing to confirm = short continu ous li ght, then double flashing: -- ·· ·· ··
STOP key
GO key
Programming lnstructions for the Uh len b rock lntellibox®
Although you use your locomotive with
Motorola * * format it is usefull to select the
DCC format II CV-Programming-bytewise II for
programming (you can use the decoder with
Motorola**-
and DCC format; please refer
to to operating instructions of the lntellibox).
And then ...
pul rh e l oco motive on the programming track
CV I Registre I default
settin
01 03
----
02 03
03
04
04 03
05 63
06
25
08
151
49
1 17
54 16
55
03
56
I 03
seit •, th e respected CV value (see the following Iist)
l- • key
inp1 1' .el ect ed value
depl l'SS th e g key to confirm (programming of the value)
prp• , ng menu and in series the mode key to continue
driv ' ope ra tion
use
bandwith of possible
chan es
locomotive address
01 - 80/127
minimum speed
01 -64
time of acceleration 01 -64
time of braking
01-64
maximum speed
01 - 64
median speed
01-64
Manufacturer's iden t fiCa tion or
08
returntodefault sell rngs
I Ioad regulation
17 = on /16 = off
---
dimmer long aux 1, Ju< 2
01-64
analoge mode 00 = all off, 01 =AC mode on,
02 = DC -mode on, 03 = all on
---
I Märklin * brake mod • 01,03 = on
02, 04 = off {Märklin*)
00, 02, 04 = off {lntellibox)
* Märklin is the registered trademark of Gebr. Märklin & Cie . GmbH, G öppil lli''"
** Motorola is the regi s tered trademark of Motorola lnc., Tempe-Phoeni x/1\!1 .1111 .1 (US A)
