WWW.Z21.EU
Model Railway Control Unit
28
• Alternate flash
Flashing effects for level crossings, etc. with adjustable ashing frequency. The alternate ash is started using the “straight/green”
command and stopped with the “branch/red” command.
Optionally also available with slow fade-up and fade-down (light bulb simulation).

Table of Contents

Question and Answer IconNeed help?

Do you have a question about the roco Z21 switch DECODER and is the answer not in the manual?

roco Z21 switch DECODER Specifications

General IconGeneral
TypeSwitch Decoder
ManufacturerRoco
Product number10836
Number of Outputs4
Output Current1A per output
Supported ProtocolsDCC
Weight50g
DCC address range1 to 2048
Power Supply12-18V AC/DC
Control MethodDCC
Programming ModePOM
