FRAME AND SHIELDS PARTS LIST
ITEM NO. PART NUMBER DESCRIPTION F&S/QTY.
1 810001 810 MAIN FRAME 1
2 810021 FRONT SIDE BOARD 2
3 810022 BACK SIDE BOARD 2
4 810038 810 PTO SHAFT SHIELD 1
5 610006 FLOW CONTROL VALVE COVER 1
6 610081 HYDRAULIC HOSE HOLDER 1
7 810011 810 GEARBOX CHAIN SHIELD 1
8 610011-A SHIELD EXTENSION 1
9 810007 FRONT SIDE SHAFT SHIELD 1
10 810008 MIDDLE SIDE SHAFT SHIELD 2
11 810009 REAR SIDE SHAFT SHIELD 1
12 HX-31-1 5/16" HEX HEAD BOLT, 1" 2
13 LW-31 5/16" LOCK WASHER 2
14 HN-31 5/16" HEX HEAD NUT 2
15 HN-38 3/8" HEX HEAD NUT 16
16 LW-38 3/8" LOCKWASHER 16
17 FW-38 3/8" FLAT WASHER 16
18 HX-38-4.5 3/8" x 4.5" HEX HEAD BOLT 16
19 HX-25-0.75 1/4" HEX HEAD BOLT, .75" 4
20 HN-25 1/4" HEX HEAD NUT 4
21 LW-25 1/4" LOCK WASHER 4
22 198250 BULLDOG SIDEWINDER JACK 1
23 410091 TWINE SHIELD 4
24 LP-25-1.75 1/4" LYNCH PIN 11
25 610004 PTO CHAIN SHIELD 1
26 810044 LEFT BEATER PANEL 1
27 8100047 RIGHT BEATER PANEL 1
28 810045 TOP BEATER BEARING SHIELD 1
29 810049 MIDDLE SIDE SHAFT SHIELD 1
17
