Roda 810 - Page 23

BEATER PANEL PARTS LIST
ITEM
NO.
PART NUMBER DESCRIPTION
Beater
Panel/QTY.
1 810001 810 MAIN FRAME 1
2 810002 LEFT BEATER PANEL 1
3 810003 RIGHT BEATER PANEL 1
4 810018 810 BOTTOM BEATER 1
5 810019 810 MIDDLE BEATER 1
6 810026 2" PILLOW BLOCK BEARING MOUNT 1
7 810029 GEARBOX CHAIN GUARD 1
8 810052 CORNER PANEL 2
9 810053 TOP BEATER PANEL BRACE BAR 2
10 810055 810 TOP BEATER 1
11 810068 #100 BEATER CHAIN 3
12 410091 TWINE SHIELD 6
13 610052 3.00" DIA x 4.00" PLASTIC TIGHTENER 2
14 610083 BEATER PANEL BRACE BAR 2
15 610101 3.00"DIA x 3.00" PLASTIC TIGHTENER 1
16 610109 BEARING SAVER, 2" 6
17 Z82-60-0808 WASHER, FLAT, 1/2" Z5 3
18 Z82-40-0808 NUT, HEX, 1/2" Z5 33
19 Z82-66-0808 WASHER, LOCK SPLIT, 1/2" Z5 39
20 Z82-01-0848 BOLT, CARRIAGE, 1/2" X 4" Z5 1
21 Z82-01-0856 BOLT, CARRIAGE, 1/2" x 5" Z5 2
22 Z82-03-0820 BOLT, HEX, 1/2" X 1-1/4" Z5 22
23 Z82-03-0824 BOLT, HEX, 1/2" X 1-1/2" Z5 14
24 Z82-03-1032 BOLT, HEX, 5/8" X 2" Z5 26
25 Z82-66-1010 WASHER, LOCK SPLIT, 5/8 Z5 28
26 Z82-40-1010 NUT, HEX, 5/8" Z5 28
27 Z82-03-1024 BOLT, HEX, 5/8" X 1-1/2" Z5 2
28 W25SDA008030 GEAR BOX, WORM DRIVE 25:1 2
29 K08-03-1037 BEARING, FLANGE 4 BOLT 2" W/LOCKING COLLAR 6
30 K08-55-1029 BEARING, PILLOW BLOCK 2" W/LOCKING COLLAR 1
31 O74-01-5040 GEARBOX, HUB CITY MODEL 66, 1:1 RATIO 1
32 FAB 10013X-1.25 SPROCKET, 100-13 1.25 BORE 1
33 FAB 10014Y-2.00 SPROCKET, 100-14 2.00 BORE 2
34 FAB 10015Y-2.00 SPROCKET, 100-15 2.00 BORE 2
35 FAB 10022Y-2.00 SPROCKET, 100-22 2.00 BORE 1
36 FAB K5050-2.75 KEY, .50 X .50 X 2.75 5
37 FAB K2525-2 KEY, .25 X .25 X 2.0 1
