Roda 810 - Page 29

WORM GEAR BREAKDOWN PARTS LIST
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 203293
RETAINING RING, EXT
1.00 SHFT
1
2 400300
PLUG, 1/2-14 NPT
SCHD W/3M
9
3 W26231
END CAP,
CP-2.312-.313 D.#0049
1
4 200301
END CAP, CP-1.50-.25
D.#0653
1
5 209843
SEAL, 1.00-1.49-.25 (R)
TC
1
6 WH3254-01
ADAPTER, HYD
4-BOLT 3/8-THRU
1
7 W15101
BEARING, CONE 1.00
VN-15101
2
8 W15245
BEARING, CUP 2.4409
VN-15245
2
9 W26R02-01
GEAR, WORM
ROLLED 2-L RH 25:1
1
10 W26R25-0
GEAR, WORM 25:1 RH
2.00 3/8 KW
1
11 804949
BEARING, CONE
TMKN# LM104949
2
12 W00100-03
SHAFT, WORM
W00100
1
13 4003VB
BUSHING, 1/2-14 NPT
TO 1/8 NPT
1
14 2003PR
PLUG, VENT 5PSI V/N
005677
1
15 W00001-0
CASTING, MACH
W260 TAP STAND
1
16 W00002-0
CASTING, MACH
W260 THRU STAND
1
17 804911
BEARING,CUP
TMKN# LM104911
2
18 819762
SEAL, 2.00-2.623-.312
(R) TC
1
19 W26262
END CAP,
CP-2.312-.313 D.#0049
1
20 W00101-02 COUPLER 1
21 W50001
RETAINING RING, INT
1.00 BORE
1
22 W00200 KEY, 1/4 x 1/4, 2.731 1
23 200200 KEY, 1/4 x 1/4, .930 1
24 W00201 KEY, 3/8 x 3/8, 1.80 1
25 SC-38-1.5
3/8" SOCKET HEAD
CAP SCREW, 1.5"
10
26 SC-38-2.25
3/8" SOCKET HEAD
CAP SCREW, 2.25"
4
