Setting obstacle impact force sensitivity MOTOR 1
If the reaction time to obstacle impact force is too long, reduce the value of the parameter. If the impact force exerted
on obstacles is too high, reduce the value of parameter

.
N.B: repeat the acquisition procedure after any change made to this parameter.

0S[QSXSVXSVUYI

= minimum obstacle impact force ...

= maximum obstacle impact force
2&SRP]YWIXLIWIWIXXMRKWMJXLIQIHMYQQSXSVXSVUYIZEPYIWEVIRSXWYMXEFPIJSVXLIMRWXEPPEXMSR

Medium motor torque. Recommended setting for adjusting force settings correctly.

= minimum obstacle impact force ...

= maximum obstacle impact force.

Maximum motor torque. May only be used if the gate is equipped with a sensing edge.

Setting obstacle impact force sensitivity MOTOR 2
If the reaction time to obstacle impact force is too long, reduce the value of the parameter. If the impact force exerted on
obstacles is too high, reduce the value of parameter

(or

MJIREFPIH

different from

).
N.B: repeat the acquisition procedure after any change made to this parameter.

0S[QSXSVXSVUYI

= minimum obstacle impact force ...

= maximum obstacle impact force
2&SRP]YWIXLIWIWIXXMRKWMJXLIQIHMYQQSXSVXSVUYIZEPYIWEVIRSXWYMXEFPIJSVXLIMRWXEPPEXMSR

Medium motor torque. Recommended setting for adjusting force settings correctly.

= minimum obstacle impact force ...

= maximum obstacle impact force.

Maximum motor torque. May only be used if the gate is equipped with a sensing edge.

Setting motor torque MOTOR 2
Increasing or decreasing the value of the parameter increases or decreases motor torque and, as a result, adjusts
obstacle detection sensitivity.
Use values below

ONLY for particularly lightweight installations not exposed to severe weather conditions (strong
winds or very cold temperatures).

!!!!(reduced motor torque = increased sensitivity).
05= 0%.
06= +8%; 07= +16%; 08= +25%; 09= +35% (increased motor torque = reduced sensitivity).

The torque is set with parameter

.
 
Setting start acceleration MOTOR 1 during opening and closing
 
Setting start acceleration MOTOR 2 during opening and closing

01= the gate accelerates rapidly at start of manoeuvre
...
10= the gate accelerates slowly and progressively at start of manoeuvre.
 
Enable electric lock release reverse impulse

Disabled.

Enabled. The controller applies a brief closing force (max. 4 s) to release the electric lock.
 
Setting opening speed (%)
  
Setting closing speed (%)

01= 60% minimum speed ... 05= 100% maximum speed.

Opening and closing approach distance setting MOTOR1

Opening and closing approach distance setting MOTOR2

from min.  to max.  of turns performed by the motor at the minimum speed.
Speed is setted by the control unit automatically and it isn’t adjustable.
 
Setting number of automatic closure attempts after activation of sensing edge or
obstacle detection (crush protection)

No automatic closure attempts.

From 1 to 3 automatic closure attempts. We recommend setting a value equal to or lower than the value set for param
eter
$
. Automatic closure is only performed if the gate is completely open.
 
Setting photocell mode during gate opening (FT1)

DISABLED. Photocell is not active or not installed.

STOP. The gate stops and remains stationary until the next command is received.

IMMEDIATE REVERSE. The gate reverses immediately if the photocell is activated during gate opening.
