Wiegand keypad
output format
0..6
Sets the PIN/keys transmission options for
Wiegand mode (details in table 3, chapter 3.2):
0 – The PIN code 1 to 10 digits and transmitted
as a BCD number
1 - The PIN code 1 to 12 digits and transmitted as
a binary number
2 - Each key pressed is immediately transmitted
to the host controller as a sequence of 4 bits plus
2 control bits
3 - Each key pressed is immediately transmitted
to the host controller as a sequence of 4 bits
without control bits
4 - Each key pressed is immediately transmitted
to the host controller as a sequence of 8 bits plus
2 control bits
5 - Each key pressed is immediately transmitted
to the host controller as a sequence of 8 bits
without control bits
6 - 1..6 keys long PIN, keys are buffered and send
to host controller as sequence of 24 bits
RS485 communication
timeout [s]
0 – function disabled
1..64
Defines time in seconds after which reader will
signal lost of communication with controller.
Available settings: 0 to 64 [s].
Optical signalisation
LED SYSTEM control
input for Wiegand
mode
0 - None
1 - IN1
2 - IN2
Defines the input line which will control LED
SYSTEM when reader operates in Wiegand mode.
LED OPEN control
input for Wiegand
mode
0 - None
1 - IN1
2 - IN2
Defines the input line which will control LED OPEN
when reader operates in Wiegand mode.
LED STATUS control
input for Wiegand
mode
0 - None
1 - IN1
2 - IN2
Defines the input line which will control LED
STATUS when reader operates in Wiegand mode.
LED SYSTEM pulsing
when card is close to
reader
0 - Off
1 - On
When option is active LED SYSTEM will be pulsing
whenever card is in the reader field.
Keypad backlight level
0..100%
Defines keypad backlight level. Value 0 switches
backlight off.
Keypad backlight
animation
0 - Off
1 - On
When option is active reader reduces keypad
backlight level when reader is not used and
restores full keypad backlight level upon any key
is pressed or card read.
Keypad backlight
dimming
0 - Off
1 - On
When option is set keypad backlight is switched
off for a while whenever card is read or key
pressed.
LED SYSTEM flash
upon card read
0 - Off
1 - On
When option is set LED SYSTEM generates single
flash whenever card is read.
LED SYSTEM flash
0 - No
When option is set LED SYSTEM generates single
