Instrument tour
R&S
®
FPC
19Getting Started 1328.7409.02 ─ 05
When you are using the connector as a trigger input, you can trigger measure-
ments with an external trigger. For more information about triggered measure-
ments, refer to the user manual.
Alternatively, you can use the connector to connect a 10 MHz reference signal to
synchronize the frequency with the external reference. Note that the reference
signal must be stronger than 0 dBm.
LAN
The LAN interface allows you to connect the R&S FPC to a local network for
remote control, printouts or data transfer. The assignment of the RJ-45 connector
supports twisted-pair category 5 UTP/STP cables in a star configuration (UTP
stands for unshielded twisted pair, and STP for shielded twisted pair).
USB port (type B)
The USB port (type B) allows you to connect the R&S FPC to a computer and
establish a remote control connection.
Device ID
The unique device identifier is provided as a barcode sticker on the rear panel of
the R&S FPC.
It consists of the serial number and a 2-character checksum.
The device ID is defined as the following example:
1310.3004.02-123456-ab
1310.3004.02 = Order number
123456 = Serial number
ab = Checksum
The instrument name is required to establish a connection to the instrument
in a LAN.
Rear panel
