3.6 Connecting AC power
The AC power connector on the rear panel of the R&S FPC allows you to connect
it to the primary power supply.
Included in the delivery of the R&S FPC are several common power plug types.
1. Select the cable with the plug type you need and firmly connect it to the
R&S FPC.
2. Connect the AC plug to the power outlet to supply the R&S FPC with power.
The R&S FPC is assembled in line with the specifications for safety class
EN61010. Therefore, it may only be connected to an outlet that has a ground
contact.
The AC power supply has the following characteristics.
● Line voltage: 100 V AC to 240 V AC
● Line frequency: 50 Hz to 60 Hz; 400 Hz
● Current: 0.6 A to 0.4 A
See also
"Connecting to power" on page 5.
3.7 Turning the R&S FPC on and off
After you have established a connection to the power supply, you can turn on the
R&S FPC.
Table 3-1: Overview of power states
Status LED Position of power switch
Off Off [0]
Standby
orange
[I]
Ready
green
[I]
Turning on the R&S FPC
► Turn on the main AC power switch on the rear panel of the R&S FPC (position
"I").
The instrument is now supplied with AC power.
Turning the R&S FPC on and off
