MIG-200MI / MIG-250MI
Quick Start Guide - Control Panels
1. Amps Display
2. Voltage Display
3. Power Indicator Light
4. Over-heat Indicator Light
5. Wire Feed Speed
6. MIG Voltage Dial
7. MMA Amps Dial
8. MIG / MMA Toggle Switch
9. Link Cable Terminal
10. Negative Terminal
1
3 4
5
2
7
8
6
10
11
12
11. Positive Terminal
12. Torch Connection Terminal
13. Power Supply
14. Power Switch
15. 240V Outlet
16. Gas Supply Nozzle
1 7. Wire Spool
18. Wire Screw
19. Wire Feed Tube
20. Thickness Adjustment Dial
9
13 14
15
16
17
18
19
20
The quick start guide can be used to aid the setup of your welder but it’s important to
fully read and understand this manual fully prior to setting up the welding machine.
