Roidmi EVA - Page 7

7
Dust Box
Base Station
Dust box release flap
Filter
Dust inlet
Function buttons
• Cleaning the mop
• Recall/inssue (robot cleaner)
• Start/pause (base station)
• Automatic dust collection
Infrared lens
Long cleaning brush
Dust collection port
Charging ports (×2)
Waste outlet
Top cover
Dirty water tank
Clean water tank
Dust bag
Display screen
Power connector
Guide wheels (×4)
Infrared lens (×2)
Cleaning disk
Water level contact
