Roidmi EVA - Product Overview

6
Product Overview
Robot Cleaner
Top cover clasp
LDS sensor
Panel
Function buttons
Bumper
Infrared receiving sensor
Dust box removal button
Wall sensors
Reset button
Cleaning brush
Dust box
Air outlet
Charging contacts (×2)
Dust collection port
Function buttons
• Area cleaning button
o Short press to clean locally, and automatically recharge after cleaning.
o Short press to pause during operation.
• Switch button
o Short press for overall cleaning, and automatically recharge after cleaning.
o Long press to switch on/off.
o Short press to pause during operation.
• Recharge button
o Short press to recharge.
Universal wheel
Carpet detection sensor
Side brush
Anti-fall sensors (×6)
Roller box release button
Driving wheels (×2)
Roller brush
Mops (×2)
Directional wheel
