Rointe D SERIES - Page 6

6
TECHNICAL SPECIFICATIONS - 150L & 200L
MODEL NUMBER
DWI150DHW2 DWI200DHW2
Storage capacity (l) 150 200
Power (W) 2,400 2,400
Depth (mm) 580 580
Width (mm) 580 580
Overall height incl T/P valve 1,060 1,220
Height excl T/P valve 960 1,120
Weight when full (kg) 194 256
Cold feed/hot draw off connections
(mm)
22 22
Maximum water supply pressure
(MPa)
0.9 0.9
System operating pressure (pre-set)
(MPa)
0.6 0.6
Expansion vessel charge pressure
(MPa)
0.3 0.3
Expansion relief valve set pressure
(MPa)
0.6 0.6
Temperature and pressure relief valve settings:
Lift pressure (MPa) 0.7 0.7
Lift temperature (ºC) 90 90
INSTALLATION KIT (OPTIONAL) - 150L & 200L
0.3 MPa pressure reducing valve • •
