ROL | ERGO Sweden W: www.rolergo.com P: +46 36 36 88 80
16
Pinch protection (optional)!
The ECS2 is equipped with an intelligent software pinch protection. During loo ration the
currents to each connected motor is continuously measured and any variation of current
is evaluated about 50 times each second! If a collision is detected system will immedia-
tely stop and back o about 2 cm!
IMPORTANT! Make sure to remove the blocking item causing the pinch before
trying to operate the table again. Failure to do so may cause injury to user or
equipment.
Soft start – Progressive acceleration allows for soft starts and stops.
Speed – the speed of the table varies with load.
4.4 Servicing of double-insulated products
In a double-insulated product, two systems of insulation are provided instead of groun-
ding. No grounding means is provided on a double-insulated product, nor is a means for
grounding to be added to the product.
Servicing a double-insulated product requires extreme care and knowledge of the sys-
tem, and is to be done only by qualified service personnel. Replacement parts for a
double-insulated product must be identical to the parts they replace. A double insulated
product is marked with the words ”DOUBLE INSULATION” or ”DOUBLE INSULATED”.
The symbol (square within a square) is also able to be marked on the product.
5. APPENDIX
5.1 Accessories, Series EE, ECS2
Handset: ECS2 /Control unit P/N se chart below
Width x depth x height 95x106x22mm, 95 gr
Stroke mm AC-O, White AC-On, White AC-O, Black AC-On, Black
420 68004741
470 68004725 68002459
500 68002469 68002466 68002463 68002460
600 68002470 68002467 68002464 68002461
650 68002471 68002468 68002465 68002462
665 68004757
AC = Anti Collision. White/Black = colour for handset houseing.
