5.3 Dimensions column system: Series EE, ECS2
with 470 stroke
31
500 stroke 1122
MAX LEVEL
WORKTOP
MIN LEVEL
500 stroke 622
60
M8x1.25
Fixing holes for crossbar
x
4
650 stroke 1235
650 stroke 585
MIN LEVEL
MAX LEVEL
WORKTOP
670 strike 1255
M8x1.25
Fixing holes for crossbar
60
647
470 stroke
31
470 stroke 1117
x
4
670 stroke 585
