Making Settings in the Menu
Assigning a continuously-variable controller
For breath (the strength of your breath), bite (the strength at which you bite the reed), thumb lever, and thumb pads, specify the following
parameters.
* Indications of “***” in the table will contain the following names.
Breath_1, Breath_2, Breath_3, Breath_4, Breath_5, Breath_6, Breath_7, Breath_8, BiteDn_1, BiteDn_2, BiteDn_3, BiteDn_4, BiteUp_1, BiteUp_2,
BiteUp_3, BiteUp_4, LeverDn_1, LeverDn_2, LeverUp_1, LeverUp_2, Pad_1, Pad_2, Pad_3, Pad_4
Parameter
Indication Value
Explanation
Assign Function *** Func
& “Aerophone Pro Editor
Parameter Guide” (PDF)
Specify the function that is assigned to a continuously-operated controller.
Input Min Value *** In Min
0
–127
Specify the minimum value (Min) and maximum value (Max) in which
controller operations are eective.
& “Function assignment (continuous operation)” (p. 16)
Input Max Value *** In Max
Output Min Value *** Out Min
0–127
Specify the minimum value (Min) and maximum value (Max) in which the
assigned function operates.
& “Function assignment (continuous operation)” (p. 16)
Output Max Value *** Out Max
Mode *** Mode Momentary, Latch
Species the operation mode.
Momentary
The function operates like a graph (p. 16), according to
how you operate the controller.
Latch
Each operation switches between Output Min Value and
Output Max Value.
The switch occurs at the mid-point value between Input Min
Value and Input Max Value.
Curve *** Curve
1: Linear 2: Exp L 3: Exp H 4: Log L 5: Log H 6: S-Shape 7: Reverse S
1: Linear 2: Exp L 3: Exp H 4: Log L 5: Log H 6: S-Shape 7: Reverse S
Species the operation curve when the operation mode is MOMENTARY.
& “Function assignment (continuous operation)” (p. 16)
Assigning a switch-type controller
For the [S1] / [S2] buttons and the side keys, specify the following parameters.
* Indications of “***” in the table will contain the following names.
S1_1, S1_2, S2_1, S2_2, [X]_1, [X]_2, [C1]_1, [C1]_2, [C2]_1, [C2]_2, [C3]_1, [C3]_2, [C4]_1, [C4]_2, [C5]_1, [C5]_2, [Tc]_1, [Tc]_2, [Ta]_1, [Ta]_2
Parameter
Indication Value
Explanation
Assign Function *** Func
& “Aerophone Pro Editor
Parameter Guide” (PDF)
Assign the function that is output via MIDI when you operate each
controller.
Release Value *** Release Val
0
–127
Specify the value when you take your nger o the button (Release)
and the value when you press the button (Press).
Press Value *** Press Val
Mode *** Mode Momentary, Latch
Species the operation mode.
MOMENTARY
The Press Value is applied while the button is pressed,
and the Release Value is applied while the button is
released.
LATCH
Each time you press the button, the Press Value and
Release Value alternate.
