CASING Q.ty
# 7772511000 VARN.+SILK. TOP CABINET AX-7 1
# 7772510000 VARN.+SILK. BOTTOM CABINET AX-7 1
# 7772509000 VARN. BATTERY COVER AX-1 1
# 7772508000 VARN. DISPLAY COVER AX-7 1
# 7772507000 SILKSCREENED PLEXIGLASS AX-7 1
KNOB BUTTON
K2478122 ROUND TAB BLACK H.8.3 6
K2478123 ROUND TAB BLACK H. 9.12 18
# K2478347 ROUND PUSHBUTTON RED H.9,12 1
# K2478348 ROUND PUSHBUTTON BLACK) H.13,5 1
7695111000 SILKSCREENED KNOB ASSY AX-1 1
SWITCH
J3169105 SWITCH TP-1101A / EVQ-PAE 05 R on RCB / on LCB 26
13159111 POWER SWITCH SSSP12114A SW2 on CPU 1
JACK, SOCKET
13449711 DC-SUPPLY SOC. HEC0470-01-630 JK2 on CPU 1
13429697 5P DIN SOCKET TCS5350-01-4051 JK1,3 on CPU 2
DISPLAY UNIT
00239767 DISPLAY TYPE LB-603VF (RED) DS1 on DISPLAY Board 1
KEYBOARD ASSY
7695105000 KEYBOARD ASSY AX1 1
NOTE: For details, refer to KEYBOARD PARTS LIST (Page 4)
PCB ASSY
# 7772501000 RIGHT CONTROL PCB ASSY AX-7 1
# 7772502000 LEFT CONTROL PCB ASSY AX-7 1
# 7772503000 D-BEAM PCB ASSY AX-7 1
# 7772504000 DISPLAY PCB ASSY AX-7 1
# 7772505000 CPU PCB ASSY AX-7 1
7695104000 CONTACT PCB ASSY + RUBBER AX1 1
IC
15229718RI I.C. 6N 137 PHOTO-COUPLER IC1 on CPU 1
15169550RI I.C. 74 HC138 DIP CMOS IC21 on CPU 1
15249111 I.C. TC7WU04 F FLAT CMOS IC13 on CPU 1
J5259127 I.C. 74 HC 10 IC16 on CPU 1
J5259113 I.C. 74 HC 390 FLAT CMOS IC14 on CPU 1
J5259128 I.C. 74 HC 393 FLAT IC17 on CPU 1
15259821 I.C. TC74HC573AF IC10 on CPU 1
00129278 I.C. SSC1080 FOB (CUSTOM IC) IC11 on CPU 1
J5259153 I.C. AT24C64N-10SC 64K EEPROM IC6 on CPU 1
15259884 I.C. TC7S08F MOS CMOS IC9 on CPU 1
15249104 I.C. TC7S04F FLAT IC12 on CPU 1
J5259149 I.C. TC74VHC541FT FLAT IC7 on CPU 1
15219183 I.C. M51953 AL (STANDING) IC8 on CPU 1
15149146 I.C. TD62583AP (INTERF.DRIVER IC) IC22 on CPU 1
15289105 I.C. UPC 4570G (OP AMP) IC20 on CPU 1
15189189 I.C. UPC 4570HA VERT. (OP.AMP.) IC1 on CPU 1
15289141 I.C. M5223FP-600D IC18,23 on CPU 2
# 7772506000 I.C. MICRO IC2 CPU A-37/AX-7 IC2 on CPU 1
TRANSISTOR
15129114 TRANSISTOR 2SC-1815GR Q7 on CPU 1
15319101 TRANSISTOR 2SC-2412K Q14 on CPU 1
15309101 TRANSISTOR 2SA-1037KR Q6 on CPU 1
15329503 TRANSISTOR DTA-124 EK CHIP Q1 on CPU 1
PARTS LIST AX-7
When ordering any parts listed in the parts list,please specify the following items in the order sheet.
QTY PART NUMBER DESCRIPTION MODEL NUMBER
Ex. 10 22575241 Sharp Key C-20/50
15 2247017300 Knob (orange) DAC-15D
Failure to completely fill the above items with correct number and description will result in delayed or
even undelivered replacement.
CONSIDERATION ON PARTS ORDERING
NOTE:
# The parts marked " # '' are new (Initial Parts).
A The parts marked " A '' are new (Initial Parts).for RES but already used by RJA
The parts marked have Safety - Related characteristics.
Use only listed parts for replacement.
<< EMI >> Component for EMC.
NNoottee :: Replacement should be made on a unit basis. No replacements available for individual parts.
Replacement only be a unit.
