Roland C-30 User Manual

12
Getting Ready to Play
1.
In the operating panel, turn the [Power] switch off (the switch should be in the outward position).
2. Connect the power cord to the body of the AC adaptor,
which is fastened to the underside of the C-30.
3.
Plug the power cord (AC adaptor) into an electrical
outlet.
• Do not use any AC adaptor other than the included
one.
• If you won’t be using the C-30 for an extended period
of time, disconnect the power cord from the electrical
outlet.
Connect the AC adaptor
Indicator
AC Outlet
AC adaptor
Power cord
To the AC adaptor connector
(already connected)
When you purchase the C-30, the AC adaptor is fastened to the bottom panel with a band. It is possible to remove the AC
adaptor, but normally you should leave it attached to the C-30.
◆ If you’ve removed the AC adaptor and wish to reattach it to the C-30,
fasten it with the band so that the printed surface of the AC adaptor is
facing up toward the bottom of the C-30, and the surface with the
indicator is facing downward.
* Fasten the AC adaptor securely so that it will not fall.
Band
Indicator
C-30_e.book 12 ページ ２００８年３月１０日 月曜日 午前１０時３１分

Roland C-30 Specifications

General

Sound effects	Reverberation
Tones quantity	6
RMS rated power	26 W
Power consumption (max)	25 W
Product color	Wood
Keys quantity	61 keys
Cables included	AC

Weight and Dimensions

Depth	450 mm
Width	1100 mm
Height	1170 mm
Weight	38000 g
