Page #11 background imageLoading...
Page #11 background image
11
CUBE-15XLSep. 2010
Measurement of the PHONES Output
Values
1. Set the panel buttons and controls as shown below.
SELECT: CLEAN
CLEAN VOLUME: 10
LEAD TYPE: EXTREME
GAIN: 10
VOLUME: 10
EQUALIZER BASS: 10
MIDDLE: 10
TREBLE: 10
POWER SQUEEZER: OFF
2. Input a 1-kHz sine wave at -40 dBm to the INPUT jack.
3. Verify that the left and right output values of the PHONES jack are both
at +1.5±2.0 dBm.
