12
CUBE-15XLSep. 2010
Block Diagram
fig.block-15XL.eps
EXTREME
METAL ZONE
DISTORTION
OVERDRIVE
INPUT
AUX IN
AC IN
HEAD AMP
CLEAN-CH
CLEAN VOLUME
LEAD VOLUME
LEAD-CH
LEAD GAIN
EQUALIZER
POWER AMP
SPEAKER 4
PHONES
POWER SUPPLY
POWER SQUEEZER
MUTE
MUTE-CONT
BASS MIDDLE TREBLE
