8
CUBE-15XLSep. 2010
Parts List
fig.-part1-e.eps
Safety Precautions:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
Note: The parts marked # are new. (initial parts) The description “Q’ty” means a necessary number of the parts per one product.
Due to one or more of the following reasons,
parts with parts code ******** cannot be supplied as service parts.
• Part supplied only as a component in a complete assembly
• Copyright does not permit the part to be supplied
• Part is sold commercially
CASING
# 5100016544 CABINET ASSY 1
# 5100016519 GRILLE 1
CHASSIS
# 5100015015 CHASSIS 1
KNOB, BUTTON
5100004351 R-KNOB 05800-515(SD000043)40A-KBG-10 7
# 22497521R0 PUSH BUTTON BLACK #521(40A-1BBG-108) 2
SWITCH
# 5100016825 SWITCH SRBM142300 1
01348745 SWITCH (PUSH) SPUP192700 2
02897801 SEESAW SWITCH SDDJE13200 94V-0 1
JACK, EXT TERMINAL
02456390 3.5MM JACK STEREO YKB21-5290 1
13449146 6.5MM JACK YKB21-5012 (W/SW) 1
13449252 6.5MM JACK YKB21-5006 (STEREO W/SW) 1
SPEAKER, BUZZER
SD000950 SPEAKER (W0804-431A) 20CM/4OHM 1
PWB ASSY
# 5100016555 MAIN BOARD ASSY 100/117V 1
* This unit includes the following parts.
# ******** MAIN BOARD 1
# ******** PRE BOARD 1
# ******** PS1 BOARD Change a fuse for high voltage. 1
# ******** POWER SQUEEZER BOARD 1
DIODE
03349978 LED (RED) L-34HDSL-FPB 1
03349989 LED (GREEN) L-34GDSL-FPB 1
POTENTIOMETER
# 5100016754 ROTARY POTENTIOMETER RD901F-20E1-15FW1B10K-00DN6 2
# 5100016756 ROTARY POTENTIOMETER RD901F-20E1-15FW1B20K-00 1
# 5100016757 ROTARY POTENTIOMETER RD901F-20E1-15FWA250K-00 2
# 5100016755 ROTARY POTENTIOMETER RD901F-20E1-15FWB100K-00 1
FUSE, FUSE HOLDER
# 5100016776 FUSE 5ST 500-R 500MA/250V for low voltage 1
03903834 FUSE 5ST 250 for high voltage 1
# 5100000592 FUSE HOLDER FC-201 2
WIRING, CABLE
# 5100016817 WIRING 184-BG433-W1 1
# 5100016820 WIRING 192-BG433-W6 1
# 5100015939 WIRING 195-BG431-W5 2
# 5100016821 WIRING 196-BG431-W6 1
# 5100016822 WIRING 196-BG431-W7 1
# 5100016823 WIRING 196-BG433-W5 1
TRANSFORMER
# SD000967 TRANSFORMER PT BG433L 100V/117V for low voltage 1
# SD000968 TRANSFORMER PT BG433H 230V/240V for high voltage 1
To Next Page
