5
CUBE-15XLSep. 2010
Exploded View (Cabinet) Parts List
No. Part Code Part Name Description Q’ty
1 SD000017 BADGE 1
2 5100016519 GRILLE 1
3 SD000950 SPEAKER (W0804-431A) 20CM/4OHM 1
5100016544 CABINET ASSY 1
* This unit includes the following parts.
4 ******** CABINET 1
6 5100015010 CORNER PROTECTOR 4
7 5100015012 TRIM SASH 1
8 12359104 RUBBER FOOT G-5R 4
5 SD000035 HANDLE WITH ESCUTHEON 1
* This unit includes the following parts.
5100011381 HANDLE 1
5100011382 HANDLE PLATE 1
5100011383 HANDLE HOLDER 2
9 ******** CHASSIS ASSY Refer to Exploded View (Chassis) (p. 6). 1
a 40230789 SCREW 3X10 OVAL MACHINE BZC 2
b 40011689 SPEED NUT M3 F-TYPE 2
c 40010367 SCREW M4X25 BINDING MACHINE BZC 4
d SD000370 PLATE WASHER 4.2X10X0.5T FEBC 4
e 40010689 SCREW 4X25 TRUSS TAPPING A FE BZC 7
f SD000975 SCREW M4X35 ORIGINAL TRUSS BZC 4
g SD000430 PLANE WASHER D11 D4.1 T1 BLACK/323-BG-405LF 4
h 40564601 SCREW M5X35 OVALHEAD MACHINE BZC 2
i 40010667 SCREW 4X16 TRUSS TAPPING A FE BZC 24
j 5100005098 SCREW 3X16 TRUSS TAPPING A BZC 4
To Next Page
