JULY.2004
CAUTIONARY NOTES
PART LIST
Due to one or more of the following reasons, parts with parts code ********
cannot be supplied as service parts.
• Part supplied only as a component in a complete assembly
• Copyright does not permit the part to be supplied
• Part is sold commercially
SPECIFICATIONS
Rated Power Output
60 W
Nominal Input Level (1 kHz)
INPUT: -10 dBu/1 M
* 0dBu”0.775Vrms
Speaker
30 cm (12 inches)
Controls
POWER Switch, SELECT Switch
<JC CLEAN Channel>
BRIGHT Switch, VOLUME Knob
<LEAD Channel>
TYPE Switch (ACOUSTIC, BLACK PANEL, BRIT COMBO,
TWEED, CLASSIC STACK, METAL STACK, R-FIER STACK,
DYNA AMP), GAIN Knob, VOLUME Knob
<EQUALIZER>
BASS Knob, MIDDLE Knob, TREBLE Knob
<PRESENCE>
PRESENCE Knob
<EFX>
EFX Knob (CHORUS, FLANGER, PHASER, TREMOLO)
<DELAY/REVERB>
DELAY/REVERB Knob
Indicators
JC CLEAN Channel, LEAD Channel, EFX, DELAY/REVERB,
POWER
Connectors
INPUT Jack (1/4” phone type)
RECORDING OUT/PHONES Jack (Stereo 1/4” phone type)
FOOT SW Jack (CH SELECT, EFX, DELAY/REVERB) (1/4”
phone type)
EXT SPEAKER Jack (1/4” phone type)
LINE OUT Jack (1/4” phone type)
TUNER OUT Jack (1/4” phone type)
Power Supply
AC 117 V, AC 230 V, AC 240 V (50/60 Hz)
AC 220 V (60 Hz)
Power Consumption
60 W
Dimensions
410 (W) x 275 (D) x 440 (H) mm
16-3/16 (W) x 10-7/8 (D) x 17-3/8 (H) inches
Weight
14.5 kg / 32 lbs
Accessory
Owner’s Manual ENGLISH”(#SD000453)
JAPANESE”(#SD000452)
Option
Foot Switch FS-5U (BOSS)
* In the interest of product improvement, the specifications and/or
appearance of this unit are subject to change without prior notice.
