Roland CUBE-60D User Manual

7
JULY.2004 CUBE-60D
6
EXPLODED VIEW(CABINET)
fig.explo-cab
THE ANGLE OF SPEAKER UNIT
＊1 THE CONNECTION OF SPEAKER TERMINAL
W7(RED)
W8(BLACK)
W8(BLUE)
b
J
b
h
a
c
b
b
b
e
b
c
1
d
J
3
4
5
5
7
8
9
12
i
a
f
g
11
6
10
The Speaker terminals face the right side .
FRONT VIEW
Refe to "EXPLODED VIEW(CHASISS)"
2
2
BADGE BACK
+
-
15
15
[PARTS]
[SCREW]
No PART CODE CATEGORY PART NAME DESCRIPTION Q’TY
1 SD000467 CASING CABINET ASSY 1
NOTE:”CABINET ASSY includes the following parts (2,4,5,7-9,12,14)
2
HARDW00067
CASING POAT TUBE 2
4 SD000066 CASING TRIM 1
5 SD000459 CASING CORNER PROTECTOR 4
7
SD000461
CASING
HANDLE RUBBER
1
8
SD000462
CASING
HANDLE PLATE
1
9
SD000463
CASING
HANDLE HOLDER
2
12
SD000078
CASING
RUBBER FOOT
4
14
SD000466
MISCELLANEOUS
ACOUSTICAL SPONGE
400X400X15T WHITE
1
3
SD000458
SPEAKER,BUZZER
SPEAKER 12’ (8OHM)
WP300RP135-00F
1
6
SD000460
CASING
GRILLE
1
10
SD000017
CASING
BADGE
1
11
SD000464
MISCELLANEOUS
HIMERON W/ADH
6 X 50 X 0.5T
3
15
SD000465
MISCELLANEOUS
EVA PACKING W/ADH
60 X 5 X 1T
4
No
PART CODE
PART NAME
DESCRIPTION
Q’TY
a
SD000068
SCREW 4X25
TRUSS TAPTITE A1 BZC
8
b
SD000432
SCREW 3X16
TRUSS TAPTITE A1 BZC
29
c
40010145
SCREW M4X25
TRUSS FE BZC
8
d
SD000019
SCREW 4X25
BINDING MACHINE BZC
8
e
SD000048
SCREW 5X35
OVALHEAD MACHINE BZC
4
f
40230778
SCREW 3X8
OVAL MACHINE BZC
2
g
40011689
SPEED NUT M3
F-TYPE
2
h
SD000370
PLATE WASHER
4.2X10X0.5T FEBC
4
i
SD000430
PLANE WASHER
D11 D4.1 T1 BLACK
4
j
********
4
