10
JULY.2004
PARTS LIST
fig.part1e
on P=PANEL PCB, on M=MAIN BOARD.
SAFETY PRECAUTIONS:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
NOTE: The parts marked # are new. (initial parts)
Due to one or more of the following reasons,
parts with parts code ******** cannot be supplied as service parts.
• Part supplied only as a component in a complete assembly
• Copyright does not permit the part to be supplied
• Part is sold commercially
The description "Q'TY" means a necessary number of the parts per one product.
CASING
Q‘TY
SD000017 BADGE 1
# SD000460 GRILLE 1
# SD000467 CABINET ASSY 1
NOTE:Spae parts for CABINET ASSY includes the following parts .
# SD000459 CORNER PROTECTOR 4
# SD000463 HANDLE HOLDER 2
# SD000462 HANDLE PLATE 1
# SD000461 HANDLE RUBBER 1
HARDW00067 PORT TUBE 2
SD000078 RUBBER FOOT 4
SD000066 TRIM 1
CHASSIS
#
SD000470 CHASSIS 1
22360705 CORD HOOK 2
# SD000471 STAY 3
KNOB,BUTTON
SD000043 KNOB 10
SD000082 PUSH BUTTON 2
SWITCH
#
SD000488 ROTARY SWITCH SR1712-0108-15F0A-N9-N RSW1 on P 1
01786012 SEESAW SWITCH JW-M11RKK 1
SD000099 PUSH SWITCH ESB64619 PSW1,PSW2 on P 2
JACK,EXT TERMINAL
13449146 6.5MM JACK YKB21-5012 (W/SW) JK1 on M 1
13449145 6.5MM JACK YKB21-5010 JK4,JK5 on M 2
13449252 6.5MM JACK YKB21-5006 (STEREO W/SW) JK2,JK7,JK8,JK9 on M 4
# SD000495 JACK S2 BNB PC-P KINKED JK6 on M 1
SPEAKER,BUZZER
#
SD000458 WP300RP135-00F SPEAKER 12’ (8OHM) 1
PWB ASSY
#
SD000399 MAIN PCB ASSY FOR 100/117V 1
NOTE:Spare parts for MAIN PCB ASSY includes the following parts.
******** MAIN BOARD ASSY 1
******** PS-1 BOARD 1
******** IN BOARD 1
******** AMP BOARD 1
******** PHO BOARD 1
******** 1
SD000110 FUSE 5ST 2A 250V FUSE 1 (100/117V) 1
NOTE: Replacement MAIN PCB ASSY is for 100V/117V version exclusive use.
MAIN PCB ASSY for 100V/117V version differs from 230V/240V version in FUSE system only.
When using PCB (230V/240V) version, be sure to make the following modifications.
1. Replace fuse (FUSE 1 on PS1 BOARD) to specific one. (P/No. F2559109 5ST 800mA/250V)
2. Please change into the check marking “100/117V T2AL 250V” from “230/240V T800mAL 250V” on PS1 BOARD.
Please refer to TABLE A.
Table A
230V/240V T800mA 250V
100V/117V
T2AL 250V
100V/117V T2AL 250V
230V/240V T800mA 250V
To Next Page
