CUBE-60D
1
SD000408 PANEL PCB ASSY
PWB ASSY
IC
F5209151 LM3886TF IC(POWER AMP IC) IC6 on M 1
# SD000493 NJM78M12DLA IC (V RGL) IC15 on M 1
# SD000494 NJM79M12DLA IC (V RGL) IC16 on M 1
# 03015923 S-80130ANMC IC (RESET) IC3 on M 1
01678512 UPC2933T-T2 IC (REGULATOR) IC9 on M 1
15289154 UPC4072G2-E1 IC (JFET OP) IC10 on M 1
02565501 TC220CCA0AF-B01(MR3) IC (DSP) IC2 on M 1
01340789 BU9480F IC (D/A CONVERTER) IC5 on M 1
# 03567234 UPD780034AGK-B17-9ET IC (CPU) IC1 on M 1
15169596 TC74HC4051AP IC (CMOS) IC7 on P 1
15189261 M5218AFP-600E IC (BIPOLAR OP AMP) IC13,IC14 on M 2
00346445 NJM2100M(TE3) IC (BIPOLAR OP AMP) IC12 on M 1
01125012 NJM4556AM IC (BIPOLAR OP AMP) IC17 on M 1
02451434 AK4552VT IC (AD/DA) IC4 on M 1
02678945 BU2090 IC IC8 on P 1
TRANSISTOR
15119144 2SA1048-GR(TPE4) TRANSISTOR Q5 on M 1
15309104 2SA1586-GR(TE85R) TRANSISTOR Q8,Q9,Q23 on M 3
15129179 2SC2458-GR(TPE4) TRANSISTOR Çp6 on M 1
15319107 2SC4116-GR(TE85R) TRANSISTOR Q10,Q11,Q19,Q20,Q24,Q25 on M 6
15329536 RN1442-A(TE85L) TRANSISTOR Q12,Q14,Q16,Q17 on M 4
15329103T0 2SK880-GR(TE85R) FET Q21,Q22 on M 2
DIODE
15019505 RD36EB2 ZENER DIODE
# 15019689 RD4.3E B2 ZENER DIODE
01019534 1SS355 TE-17 SWITCHING DIODE D5,D6,D7,D10,D11 on M 5
SD000045 LED RED LED1,LED2,LED3,LED6 on P 4
SD000044 LED GREEN LED5 on P 1
SD000239 1N4007G 1A 1000V P=10MM DIODE
02457445 1SS367 DIODE D8,D9 on M 2
F5039116 FL402 BRIDGE DIODE BD1 on M 1
15019654 RD16EB2-T1 DIODE
SD000120 AM152 BRIDGE DIODE BD2 on M 1
15339120T0 1SS302(TE85R) ARRAY DIODE DA1,DA2,DA3,DA4,DA5,DA8 on M 6
RESISTOR
00344278 EXBV8V102JV RESISTOR ARRAY RA3,RA4 on M 2
15409113 EXBV8V103JV RESISTOR ARRAY RA1,RA2 on M 2
C0000044 0.1 OHM 2W METAL OXIDE RESISTOR R17 on M 1
# SD000510 120 2W METAL OXIDE RESISTOR R141 on M 1
C0000042 27 OHM 1/2W METAL OXIDE RESISTOR R18 on M 1
C0000004 82 OHM 1/2W CARBON RESISTOR R146,R147 on M 2
13749791T0 SR25TRE 561 J CARBON RESISTOR R38,R69 on M 2
POTENTIOMETER
#
SD000487 RK09L1140C1T 10KB ROTARY POTENTIOMETER VR1-9 on P 9
CAPACITOR
00239523 AMZV0050J183 0200 POLYEST. CAPACITOR C3 on M 1
00239601 AMZV050J104 200 0.1UF 50V POLYEST. CAPACITOR C16,C18,C45 on M 3
SD000246 EC8472MH 4700P/250V LINE CAPACITOR (SEC) C152,C140 on M 2
SD000247 PY17FY472ML0 4700P/250V LINE CAPACITOR (PRI) C151 on M 1
# SD000509 1000UF/35V 105DO ELECTROLYTIC CAPACITOR C153,C142 on M 2
# SD000507 100UF/25V 105DO ELECTROLYTIC CAPACITOR C30,C33,C68,C70,C112,C146,C149 on M 7
# SD000505 10UF/50V 105DO ELECTROLYTIC CAPACITOR C136,C11 on M 2
# SD000504 1UF/50V 105DO ELECTROLYTIC CAPACITOR C44,C65,C137,C74,C75,C195,C197 on M 7
# SD000508 220UF/25V 105DO ELECTROLYTIC CAPACITOR C145,C156 on M 2
# SD000506 47UF/50V 105DO ELECTROLYTIC CAPACITOR C138,C2 on M 2
SD000352 3300UF/50V ELECTORIC CAPACITOR C141,C139 on M 2
CRYSTAL,RESONATOR
02673278 CX-49G 11.2896MHZ CRYSTAL X2 on M 1
02673267 CX-49G 5MHZ CRYSTAL X1 on M 1
