12
JULY.2004
FUSE,FUSE HOLDER
F2559307 RADIAL TYPE MRT 100MA/250V FUSE6 on M 1
F2559305 RADIAL TYPE MRT 2 A FUSE2,FUSE3 on M 2
# SD000503 FUSE(RADIAL TYPE) MRT315MAL/250V FUSE4,FUSE5 on M 2
SD000251 FUSE HOLDER FC-201 for FUSE1 on M 2
F2559504 FUSE 5ST 2A/250V FUSE1 on M 1
CONNECTOR
13369570 B2B-PH-K-S (2P) CONNECTOR CN5 on M 1
03014001 B5B-PH-K-S JST(PB FREE) CONNECTOR CN6 on M 1
13369981 B5P-VH 7A/250V CONNECTOR CN13 on M 1
03014023 B9B-PH-K-S JST(PB FREE) CONNECTOR CN8 on M 1
WIRING, CABLE
#
SD000490 WIRING W4 (9P WHITE) CN9 on M 1
# SD000498 WIRING W3 (5P) CN14 to CN15 on M 1
# SD000491 WIRING W5 (5P WHITE) CN7 on M 1
# SD000492 WIRING W6 (3P WHITE) WP13 to WP14 on M 1
# SD000496 WIRING W1 (2P) CN4 1
# SD000502 WIRING W10 (1P) WP7,WP10,WP11 3
# SD000501 WIRING W9 (1P) WP1,WP2 2
# SD000499 WIRING W7 (1P RED) SP1 1
# SD000474 WIRING W11 (1P BLUE) CHASSIS TO SPEAKER 1
# SD000500 WIRING W8 (1P BLACK) SP2 1
# SD000497 WIRING W2 (12P) WP15 to WP16 1
TRANSFORMER
#
SD000469 ST-11785 TRANSFORMER 230V/240V 1
# SD000468 ST-11784 TRANSFORMER 100V/117V 1
AC CORD ASSY (Installed)
SD000012 SP-023 230V AC CORD 1
SD000095 SP-18E 100V AC CORD 1
SD000014 SP-301 117V AC CORD 1
SD000015 SP-502B 240V AC CORD 1
SD000016 SP-60 230VE AC CORD 1
SCREWS
40011756 FLANGE HEX NUT M3 ZC for AC CORD BUSH 1702B 2
SD000432 SCREW 3X16 TRUSS TAPTITE A1 BZC for TRIM, CORNER 29
SD000068 SCREW 4X25 TRUSS TAPTITE A1 BZC for GRILLE, RUBBER FOOT 8
40010145 SCREW M4X25 TRUSS FE BZC for CHASSIS 8
# SD000484 JACK NUT S2 BNB for JK6 (EXT SP) 1
# SD000485 JACK WASHER S2 BNB for JK6 (EXT SP) 1
40013012 SCREW M4X10 PAN W SEMS FE BZC for TRANSFORMER 4
40011423 SCREW M3X6 PAN SEMS FECM for PCB 5
SD000103 SCREW M4X25 PAN PACHINE W/SW BZC for AC CORD HOOK 2
40012867 SCREW M3X8
PAN MACHINE W/SW+PW ZC
for STAY, HEATSINK
19
40237101 SCREW M3X8
PAN MACHINE W/SW+PW FE BZC
for STAND OFF, HEATSINK HOLDER, TERMINAL
9
40013078 SCREW M3X10 PAN MACHINE W/SW FE ZC for POWER IC 1
SD000048 SCREW 5X35 OVALHEAD MACHINE BZC for HANDLE 4
40230778 SCREW 3X8 OVAL MACHINE BZC for LOGO BADGE 2
22150501 STAND OFF M3 L10C for PCB 3
40011889
EXTERNAL TOOTH WASHER M4
FECM
for Wiring GND to CHASSIS 1
40011878
M3 EXTERNAL TOOTH WASHER
FECM
for Wiring GND to STAY 1
40011767 FLANGE HEX NUT M4 FE ZC for Wiring GND 2
40011689 SPEED NUT M3 F-TYPE for LOGO BADGE 2
SD000430 PLANE WASHER D11 D4.1 T1 BLACK for GRILLE 4
SD000019 SCREW 4X25 BINDING MACHINE BZC for SPEAKER 8
40010301 SCREW M3X20 BINDING MACHINE BZC for AC CORD BUSH 1702B 2
SD000370 PLATE WASHER 4.2X10X0.5T FEBC for RUBBER FOOT 4
SD000042 JACK NUT 7
17048630 VR ACCESSORY NUT M9 for VOLUME, ROTARY SWITCH 10
17048631 VR ACCESSORY WASHER M9 for VOLUME, ROTARY SWITCH 10
PACKING
SD000264 EAN CAP PAD 8
# SD000457 BOTTOM PAD CARDBOARD 1
# SD000456 TOP PAD CARDBOARD 1
# SD000455 PACKING CASE 1
To Next Page
