Roland CUBE-STEX - Wiring Harness and Cushions; Internal Wiring Cable Specifications; Cushion Component Listings

20
Apr. 2014 CUBE-STEX
Wirings
Cusions
No. Part Code Part Name Description Q’ty
1 5100038992 WIRING W12 1007#26 3X165-PHR-SAN-F 1 3P
2 5100038996 WIRING W6 1007#26 8X230-PHR-SAN-F 1 8P
3 5100038997 WIRING W8 1007#26 10X165-PHR-SAN-F 1 10P
4 5100033888 WIRING W2 1 10P
5 5100038993 WIRING W11 1007#26 4X110-PHR-SAN-F 1 4P
6 5100038995 WIRING W9 1007#26 7X90-PHR-SAN-F 1 7P
7 5100039001 WIRING W5 1015#22 1 3P
8 5100039002 WIRING W7 1015#22 1 3P
9 5100039000 WIRING W16 1007#26 1 3P
10 5100039007 WIRING W17 1015#22-RED 1X160 1 1P (RED)
11 5100039008 WIRING W18 1015#22-BLK 1X160 1 1P (BLACK)
12 5100039003 WIRING W1 1015#22-RED 1X480 1 1P, SLEEVE (RED)
13 5100039004 WIRING W2 1015#22-BLK 1X480 1 1P, SLEEVE (BLACK)
14 5100039005 WIRING W3 1015#22-ORG 1X330 1 1P, SLEEVE (ORANGE)
15 5100039006 WIRING W4 1015#22-BRN 1X330 1 1P, SLEEVE (BROWN)
16 5100039009 WIRING W19 1015#22-ORG 1X165 1 1P (ORANGE)
17 5100039010 WIRING W20 1015#22-BRN 1X160 1 1P (BROWN)
18 5100038994 WIRING W14 1007#26 6X235-PHR-SAN-F 1 6P
19 5100038998 WIRING W13 1007#26 10X175-PHR-SAN-F 1 10P
20 5100038999 WIRING W15 1007#26 11X350-PHR-SAN-F 1 11P
No. Part Code Part Name Description Q’ty
1, 3, 18 5100039404 CUSHION WIRING C 3
2, 17, 19 5100039405 WIRING D 3
19 5100039403 CUSHION WIRING B 1
