Appendix
206
r
E-60/E-50 Music Workstation
● Delay Feedback (–98%~0~98%)—Adjusts the amount of
the delay sound that’s fed back into the effect. Negative (–)
settings invert the phase.
● Delay HF Damp (200~8000Hz, Bypass)—Adjusts the fre-
quency above which sound fed back to the effect is filtered
out. If you don’t want to filter out any high frequencies, set
this parameter to BYPASS.
● Delay Balance (D100:0W, D50:50W, D0:100W)—Adjusts
the volume balance between the sound that is sent
through the delay (W) and the sound that is not sent
through the delay (D).
● Level (0~127)—Output level.
36. Chorus‰ DLY
This effect connects a chorus and a delay in series.
● Chorus Pre Delay (0.0~100.0ms)—Adjusts the delay
between the incoming direct signal and the moment when
the chorus starts working.
● Chorus Rate (0.05~10.0Hz)—Frequency, i.e. modulation
speed.
● Chorus Depth (0~127)—Modulation intensity.
● Chorus Balance (D100:0W, D50:50W, D0:100W)—Vol-
ume balance between the direct sound (D) and the chorus
sound (W).
● Delay Time (0.0~500.0ms)—Adjusts the time until the
delay is heard.
● Delay Feedback (–98%~0~98%)—Adjusts the amount of
the delay sound that’s fed back into the effect. Negative (–)
settings invert the phase.
● Delay HF Damp (200~8000Hz, Bypass)—Adjusts the fre-
quency above which sound fed back to the effect is filtered
out. If you don’t want to filter out any high frequencies, set
this parameter to BYPASS.
● Delay Balance (D100:0W, D50:50W, D0:100W)—Adjusts
the volume balance between the sound that is sent
through the delay (W) and the sound that is not sent
through the delay (D).
● Level (0~127)—Output level.
37. Flanger‰ DLY
This effect connects a flanger and a delay in series.
● Flanger Pre Delay (0.0~100.0ms)—Adjusts the delay time
from when the direct sound begins until the flanger sound
is heard.
● Flanger Rate (0.05~10.0Hz)—Frequency, i.e. modulation
speed.
● Flanger Depth (0~127)—Modulation intensity.
● Flanger Feedback (–98%~0~98%)—Adjusts the propor-
tion of the flanger sound that is fed back into the effect.
Negative (–) settings will invert the phase.
● Flanger Balance (D100:0W, D50:50W, D0:100W)—
Volume balance between the direct sound (D) and the
flanger sound (W).
● Delay Time (0.0~500.0ms)—Adjusts the time until the
delay is heard.
● Delay Feedback (–98%~0~98%)—Adjusts the amount of
the delay sound that’s fed back into the effect. Negative (–)
settings invert the phase.
● Delay HF Damp (200~8000Hz, Bypass)—Adjusts the fre-
quency above which sound fed back to the effect is filtered
out. If you don’t want to filter out any high frequencies, set
this parameter to BYPASS.
● Delay Balance (D100:0W, D50:50W, D0:100W)—Adjusts
the volume balance between the sound that is sent
through the delay (W) and the sound that is not sent
through the delay (D).
● Level (0~127)—Output level.
38. CHO‰ Flanger
This effect connects a chorus and a flanger in series.
● Chorus Pre Delay (0.0~100.0ms)—Adjusts the delay
between the incoming direct signal and the moment when
the chorus starts working.
● Chorus Rate (0.05~10.0Hz)—Modulation frequency of the
chorus effect.
● Chorus Depth (0~127)—Modulation intensity of the cho-
rus effect.
● Chorus Balance (D100:0W, D50:50W, D0:100W)—Vol-
ume balance between the direct sound (D) and the chorus
sound (W).
● Flanger Pre Delay (0.0~100.0ms)—Adjusts the delay time
from when the direct sound begins until the flanger sound
is heard.
● Flanger Rate (0.05~10.0Hz)—Modulation frequency of
the flanger effect.
● Flanger Depth (0~127)—Modulation intensity of the
flanger effect.
● Flanger Feedback (–98%~0~98%)—Adjusts the propor-
tion of the flanger sound that is fed back into the effect.
Negative (–) settings will invert the phase.
● Flanger Balance (D100:0W, D50:50W, D0:100W)—
Volume balance between the direct sound (D) and the
flanger sound (W).
● Level (0~127)—Output level.
39. CHO/Delay
This effect connects a chorus and a delay in parallel. (“Paral-
lel” means that the input signal is processed by two effects
that do not interact.)
● Chorus Pre Delay (0.0~100.0ms)—Adjusts the delay
between the incoming direct signal and the moment when
the chorus starts working.
● Chorus Rate (0.05~10.0Hz)—Frequency, i.e. modulation
speed.
● Chorus Depth (0~127)—Modulation intensity.
● Chorus Balance (D100:0W, D50:50W, D0:100W)—Vol-
ume balance between the direct sound (D) and the chorus
sound (W).
● Delay Time (0.0~500.0ms)—Adjusts the time until the
delay is heard.
● Delay Feedback (–98%~0~98%)—Adjusts the amount of
the delay sound that’s fed back into the effect. Negative (–)
settings invert the phase.
● Delay HF Damp (200~8000Hz, Bypass)—Adjusts the fre-
quency above which sound fed back to the effect is filtered
out. If you don’t want to filter out any high frequencies, set
this parameter to BYPASS.
● Delay Balance (D100:0W, D50:50W, D0:100W)—Adjusts
the volume balance between the sound that is sent
through the delay (W) and the sound that is not sent
through the delay (D).
● Level (0~127)—Output level.
