Oct.2003
12
J3809139 OXIDE RESISTOR 2.2 OHM 3W R78,83 on JKB 2
01783623 RESIST. 2010 10 OHM1/2W 5% R210,89 on MB 2
POTENTIOMETER
00459901 ROT. POT. 10KB 14K 1230 VR1 on VB 1
CAPACITOR
J3629144 ELCTRL.COND. 470UF 16V AX C5 on CB 1
13639154 ELECTRL.COND.-V 1000UF 16V on JKB 1
J3469156 ELECTR. COND. 33U 35V P.5 C26,50,51,60,63,91,97,109 on JKB 8
J3629122 ELECTRL.COND.-V 1000UF 25V C30,54,42,73 on JKB 4
J3629103 ELECTRL.COND. 100U 25V P5 on JKB 12
J3629104 ELECTRL.COND. 10U 50V P5 C23,28,46,52,67,300,301 on JKB 7
J3629105 ELECTRL.COND. 47U 50V P5 on JKB 1
J3629107 ELECTRL.COND. 1UF 100V P5 C9,6,40 on JKB 3
J5369104 ELECTR. COND. RV2 10U 16V (SMD) C17,24,127,139,140,148,173,210,277,287,293,294,315,
317,318,319,326,328,330 on MB 19
J5369105 ELECTR. COND. RV3 33U 16V (SMD) C1,13,16,120,290,291,292,348,349,206,323,329 on MB 13
J5369106 ELECTR. COND. RV2 1U 50V (SMD) C49,302 on MB 2
J3629149 ELECTR.COND. 100U 16V H.7 C4 on CB 1
J3629137 ELECTR. COND. 33U 16V H.7 C2,6,7 on CB 3
13649103J0 UNPOL.COND. 10U 50 P5 C89,96,104,107 on JKB 4
INDUCTOR, COIL, FILTER
<<EMI>> 12449382RI NOISE SUP. PLT1-R53C FL1 on JKB 1
<<EMI>> 12449380 NOISE SUP. EXC-ELDR25V L1,2 on HPB 2
<<EMI>> 00452034 CHIP NOISE SUP. BK2125HM102 on MB 34
<<EMI>> 12449355 NOISE SUP. FBR07H850TB00 L1,6,8 on JKB 3
<<EMI>> 01340834 FERRITE BEAD EXCML 20A390 L2,3,4,5 on JKB 4
<<EMI>> J2399109 NOISE SUP. ELKE471FA CHIP FL3 on MB 1
CRYSTAL, RESONATOR
00901912 X-TAL 24.576 MHZ MA-406 X3 on MB 1
01340745 XTAL MA-406 12MHZ X4 on MB 1
01126267 X-TAL 7.056 MHZ MA-406 X1 on MB 1
# J2389104 RESONATOR CSTLS4M00G53-BO (4MHZ) X1 on JKB 1
CONNECTOR
13419677RI 16P FEM. CONNECTOR AMP 1.27 CN8,9 on MB / RIGHT, LEFT Contact B 4
13369689RI 20P FEM. CONNECTOR AMP 1.27 CN13 on MB 1
J3429122 14P FEM. CONNECTOR AMP 1.27 CN3 on MB 1
# J3429129 FEMALE CONNECTOR 18P AMP1,27 CN2 on MB 1
# J3429130 8P FEMALE CONNECTOR PHR-8 P.2 JST CN16 on MB / CN5 on CB 2
13369688RI 4P MALE CONN. P 2.5 M CN5 on JKB / CN1 on SWITCH B 2
J3439121 6P MALE CONN. P.2 M CN3 on JKB 1
J3439143 34P MALE CONN. P. 1.27 M CN7 on MB 1
J3439123 6P MALE CONN. P. 2 M 90 CN2 on VB / CN3 on JKB 2
J3439142 3P MALE CONNECTOR P/2.5 M CN2 on JKB 1
J3439148 7P MALE CONNECTOR P.2 M CN5 on HPB, CN8 on JKB 2
J3439184 4P MALE CONNECTOR 90 P.2.5M 5046-04 CN6 on JKB 1
# J3439189 8P MALE CONNECTOR B8B-PH-K-S P.2 JST CN5 on CB, CN16 on MB 2
WIRING, CABLE
K3468221 4P CABLE (66) -2C D/R From CN5 on JB to CN1 on SWITCH B 1
# K3468280 4P CABLE (76/50) P.2,5 -1C From CN6 on JB to SPEAKERS 1
# K3468281 34P FLAT CABLE (18) + FERRITE -2C D/D From CN7 on MB to FDD 1
J3469159 AWG18 CBL (12) GREEN + FASTON (2) 2
# 7775311000 3P CABLE ASSY 2V/1R (24) 3+4P CONNEC. From CN2 on JKB to FDD 1
# 7775314000 2P CABLE ASSY COAXIAL (24) -2C P.2 D/R From CN3 on JKB to CN2 on VB 1
7712023000 7P CABLE ASSY (72) -2C P.2 D/R From CN5 on HPB to CN8 on JKB 1
# 7775312000 8P CABLE ASSY (40) -2C P.2 JST D/R From CN16 on MB to CN5 on CB 1
7771707000 16P CABLE ASSY (28)+ALUM. -2C D/R From CN9 on MB to RIGHTContact B 1
7771708000 16P CABLE ASSY (38)+ALUM. -2C D/R From CN8 on MB to LEFTContact B 1
# 7775313000 18P CABLE ASSY (32) -C1+1 D/D From CN2 on MB to CN2 on CB 1
AC INLET
13449726 DC SUPPLY SOCKET HEC 2305-01-230 JK7 on JKB 1
SCREW
J2289122 SCREW 2.2X6 TC TC BRUN 2
J2289101 SELF TAP.SCREW 2.9X 6 TC TC 9
J2289102 SELF TAP.SCREW 2.9X10 TC TC 2
J2289126 SELF TAP.SCREW 2.9X 8 TCTCPRBZ 2
J2289125 SCREW 2.9X10 TC TC PR TROP 49
J2289130 SCREW 2.9X13 TC TC PR TROP 37
J2289160 SELF TAP.SCREW 2.9X13 TCTCPR BR 1
J2289108 SELF LOCK.SCREW M3X10 TCTC H.6 7
J2289193 SELF LOCK.SCREW M3X6 TC TC H.6 9
J2289186 SCREW 3.5X16 TCPR TFR H.8 BRUN 8
