EXR-5
11
KEYBOARD ASSY
7626921001 61 KEY KEYBOARD TP/7BA 2ND 1
NOTE: For details, refer to KEYBOARD PARTS LIST (Page 8)
PCB ASSY
# 7775303000 CONTROL PCB ASSY EXR-5 1
# 7775302000 JACK SOCKET PCB ASSY EXR-5 1
# 7775304000 HEADPHONE PCB ASSY EXR-5 1
# 7775305000 VOLUME PCB ASSY EXR-5 1
# 7775306000 SWITCH PCB ASSY EXR-5 1
# 7775301000 CPU ASSY (MICRO ROM) EXR-5 1
7624508000 CONTACT PCB 61 KEYS W/RUBBER 1
IC
15229718RI I.C. 6N 137 PHOTO-COUPLER IC2 on JKB 1
A 01907778 I.C. HD64F7017F28 IC2 on MB 1
15169550RI I.C. 74 HC138 DIP CMOS IC3 on CB 1
J5159107 I.C. 74 HC574 CMOS IC2 on CB 1
15249111 I.C. TC7WU04 F FLAT CMOS IC23 on MB 1
J5259102 I.C. 74 HC 273 FLAT CMOS IC48 on MB 1
00129278 I.C. SSC1080 FOB (CUSTOM IC) IC9 on MB 1
01342978 I.C. TC160G22AF-1253 FLAT IC3 on MB 1
J5259120 I.C. HM5118160CJ-6 FLAT IC18 on MB 1
01126612 I.C. LC324260AJ60/AS4C256K16E050JCT IC28 on MB 1
# J5259160 I.C. AM29F160DB-75EC 16M FLASH IC36,37,38 on MB 3
15199780 I.C. HD63266FP-64A FLAT IC8 on MB 1
01679978 I.C. RA09-002 (XP6) CUSTOM IC24 on MB 1
# J5259161 I.C. M66291GP USB CONTROLLER IC39 on MB 1
A 03344445 IC MX3000AS IC3 on JKB 1
15259885 I.C. TC7S32F CMOS IC7,27 on MB 2
K5258146 I.C. TC74VHC139F FLAT IC1 on MB 1
15249121 I.C. TC7W04F IC4 on MB 1
J5259150 I.C. TC 7W32F FLAT IC35 on MB 1
# J5259162 I.C. TC 74VHCT00AF IC34 on MB 1
02340756 I.C. TC7WH32FU (FLAT) IC30 on MB 1
02565212 I.C. SN74LV245A-PW IC40,44,46 on MB 3
J5169106 I.C. 74LS04 TTL IC1 on JKB 1
15189250 I.C. M5218 AL (STANDING) IC5,6,9 on JKB 3
15189189 I.C. UPC 4570HA VERT. (OP.AMP.) IC8 on JKB 1
J5189102 I.C. TD 62593 AP DIP IC1 on CB 1
15199937 I.C. M51953 BFP FLAT IC5 on MB 1
01451578 I.C. AK4324-VF-E2 DAC IC31 on MB 1
15189261 I.C. BA 5218 AFP-600E FLAT IC47 on MB 1
J5199110 I.C. L4940V5 IC7 on JKB 1
01670890 I.C. PQ3DZ53U REGULATOR IC21 on MB 1
J5259133 I.C. TA7805 AF IC29 on MB 1
# J5259163 I.C. LP2950 CZ-3.3 IC10 on JKB 1
00562601 I.C. LA4705 POWER AMP IC4 on JKB 1
# 7775307000 I.C. MICRO IC2 CPU EXR-5 IC2 on MB 1
# 7775308000 I.C. FLEX ROM IC26 CPU EXR-5/EXR-3 IC26 on MB 1
TRANSISTOR
15129114 TRANSISTOR 2SC-1815GR Q18,6 on JKB 2
15129136 TRANSISTOR 2SC-2878-A/B Q2,3,19,20 on JKB 4
15129602 TRANSISTOR 2SD-667C Q7 on JKB 1
15129164 TRANSISTOR DTC-114ES Q4,5,17 on JKB 3
15119163 TRANSISTOR RN2227 Q2,3 on CB 2
15119141 TRANSISTOR DTA-114 ESATP Q18,6 on JKB 1
DIODE
15019159RI DIODE 1N-4148 D15,16 on JB/on CB 185
15119126 DIODE 1SS-133T REDUCED PITCH D1,2,3,9,14 on JKB 5
15339108 DIODE DA-204K D1,2 on MB 2
00019356 DIODE 1SR139-400 T-32 D10,12 on JKB 2
01905134 SCHOTTKY DIODE MA7D49 D13 on JKB 1
# J5019118 LED DIODE SLI-343DC 3F/UV ORANGE D9,10,11,12,21,22,23,24,35,36 on CB 11
# J5019119 LED DIODE SLA 560EBT XM GREEN D33 on CB 1
# J5019120 LED DIODE SLA 560BBT3F XJ (BLU) D45 on CB 1
RESISTOR
J3709119 RESISTOR 4.7K OHM 1/8W 5% 6
J3919104 RESISTOR ARRAY EXB-A10E-103-J RA2,5,10,14,17,22,24,34,38,26,27,28,29 on MB 13
J3919107 RESISTOR ARRAY EXB-V8V-101-JV RA33,40,41,42 on MB 4
J3919108 RESISTOR ARRAY EXB-V8V-103-JV RA8,19,20,21,25 on MB 5
J3919109 RESISTOR ARRAY EXB-V8V-470-JV RA3,4,6,7,9,12,13,15,16,18 on MB 10
J3919110 RESISTOR ARRAY EXB-V8V-R00-0V RA55,56,57,58,59,60 on MB 6
00126101 RESISTOR ARRAY EXB-V8V-221-JV RA36,37,39 on MB 3
J3919115 RESISTOR ARRAY EXB-V8V-223-JV RA30,31,32 on MB 3
J3809134 UNINFL.RES. 27 OHM 0.6W 5% R35 on CB 1
J3809158 ININF. RESISTOR 3.3 0.6W 5% R33 on CB 1
J3809150 UNINFL.RES. 33 OHM 1/4W 5% R5,6,7,8,9,10,11 on CB 8
J3809156 UNINFL. RES. 47 OHM 0.6W 5% R1,2,3,4 on HPB 4
