MIDI Implementation
13
40 03 17 00 00 01 00–7F EFX Send Level to Reverb
* Set to 0 when EFX type is changed.
40 03 18 00 00 01 00–7F EFX Send Level to Chorus
* Set to 0 when EFX type is changed.
40 03 1A 00 00 01 00–7F EFX Depth Dry 100%–EFX 100% 7F
7Part Parameters
This instrument has 16 parts. Parameters that can be set individually for each Part are called Part parameters.
If you use exclusive messages to set Part parameters, specify the address by Block number rather than Part Number (normally the same number as the MIDI channel). The Block
number can be specied as one of 16 blocks, from 0 (H) to F (H).
The relation between Part number and Block number is as follows.
x...BLOCK NUMBER (0–F), Part 1 (MIDI ch = 1) x = 1
Part 2 (MIDI ch = 2) x = 2
: : :
Part 9 (MIDI ch = 9) x = 9
Part10 (MIDI ch = 10) x = 0
Part11 (MIDI ch = 11) x = A
Part12 (MIDI ch = 12) x = B
: : :
Part16 (MIDI ch = 16) x = F
* The controller numbers are indicated as “CC#” in the following map.
Address (H) Size (H) Data (H) Parameter Description Default Value (H) Description
40 1x 00 00 00 02 00–7F TONE NUMBER CC#00 VALUE 0–127 00 0
40 1x 01# 00–7F P.C. VALUE 1–128 00 1
40 1x 02 00 00 01 00–10 Rx. CHANNEL 1–16, OFF Same as the Part Number
40 1x 03 00 00 01 00–01 Rx. PITCH BEND OFF/ON 01 ON
40 1x 04 00 00 01 00–01 Rx. CH PRESSURE OFF/ON 01 ON
40 1x 05 00 00 01 00–01 Rx. PROGRAM CHANGE OFF/ON 01 ON
40 1x 06 00 00 01 00–01 Rx. CONTROL CHANGE OFF/ON 01 ON
40 1x 07 00 00 01 00–01 Rx. POLY PRESSURE OFF/ON 01 ON
40 1x 08 00 00 01 00–01 Rx. NOTE MESSAGE OFF/ON 01 ON
40 1x 09 00 00 01 00–01 Rx. RPN OFF/ON 01 ON
40 1x 0A 00 00 01 00–01 Rx. NRPN OFF/ON 00 (01*) OFF (ON*)
* When “GM1 System On” and “GM2 System On” are received, Rx. NRPN will be set OFF. When “GS Reset” is received, it will be set ON.
40 1x 0B 00 00 01 00–01 Rx. MODULATION OFF/ON 01 ON
40 1x 0C 00 00 01 00–01 Rx. VOLUME OFF/ON 01 ON
40 1x 0D 00 00 01 00–01 Rx. PANPOT OFF/ON 01 ON
40 1x 0E 00 00 01 00–01 Rx. EXPRESSION OFF/ON 01 ON
40 1x 0F 00 00 01 00–01 Rx. HOLD1 OFF/ON 01 ON
40 1x 10 00 00 01 00–01 Rx. PORTAMENTO OFF/ON 01 ON
40 1x 11 00 00 01 00–01 Rx. SOSTENUTO OFF/ON 01 ON
40 1x 12 00 00 01 00–01 Rx. SOFT OFF/ON 01 ON
40 1x 13 00 00 01 00–01 MONO/POLY MODE Mono/Poly 01 Poly
(= CC# 126 01 / CC# 127 00)
40 1x 15 00 00 01 00–02 USE FOR RHYTHM PART 0 = OFF 00 at x ≠0 OFF at x ≠0
1 = MAP1 01 at x = 0 MAP1 at x ≠0
2 = MAP2
* This parameter sets the Drum Map of the Part used as the Drum Part. This instrument can simultaneously (in dierent Parts) use up to two Drum Maps (MAP1, MAP2). With
the initial settings, Part10 (MIDI CH = 10, x = 0) is set to MAP1 (1), and other Parts are set to normal instrumental Parts (OFF (0)).
40 1x 16 00 00 01 28–58 PITCH KEY SHIFT -24–+24 [semitones] 40 0 [semitones]
40 1x 17 00 00 02 00 08–0F 08 PITCH OFFSET FINE -12.0–+12.0 [Hz] 08 00 (80) 0 [Hz]
40 1x 18# (08–F8) Use nibblized data.
* PITCH OFFSET FINE allows you to alter, by a specied frequency amount, the pitch at which notes will sound. This parameter diers from the conventional Fine Tuning (RPN
#1) parameter in that the amount of frequency alteration (in Hertz) will be identical no matter which note is played. When a multiple number of Parts, each of which has been
given a dierent setting for PITCH OFFSET FINE, are sounded by means of an identical note number, you can obtain a Celeste eect.
40 1x 19 00 00 01 00–7F PART LEVEL 0–127 64 100
(= CC# 7)

Roland fp-30 Specifications

General

Certification	FCC, CE
Sound effects	Ambience, Brilliance
Tones quantity	35
Pedals quantity	1
RMS rated power	24 W
Speaker diameter	120 mm
Number of speakers	2
Metronome tempo range	20 - 250 bpm
Metronome beats per bar	0, 2, 3, 4, 5
Maximum polyphony (notes)	128
Bluetooth version	4.0
USB connector type	USB Type-A, USB Type-B
Headphone connectivity	3.5 mm
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (max)	22 W
Power consumption (min)	3 W
Built-in display	No
Country of origin	Malaysia
Tuning frequency	415.3 - 466.2 Hz
Demo songs quantity	30
Transposition range	-6 - 5 octave(s)
Sound pressure level	120 dB
Product color	White
Keys quantity	88 keys
Number of keyboard sensitivity levels	5

Weight and Dimensions

Depth	284 mm
Width	1300 mm
Height	150 mm
Weight	14100 g
