Roland GR-33 - MIDI Implementation

105
Chapter 11 Appendices
Chap.
11
MIDI Implementation
Model: GR-33
Date: Jul. 21, 2000
Version: 1.01
1. Recognized Receive Data
■Channel Voice Message
●Note Off
STATUS SECOND THIRD
8nH kkH vvH
9nH kkH 00H
n=MIDI Channel Number: 0H - FH (0 - 15) 0=ch.1 15=ch.16
kk=Note Number: 00H - 7FH (0 - 127)
vv=Velocity: 00H - 7FH (0 - 127)
●Note On
STATUS SECOND THIRD
9nH kkH vvH
n=MIDI Channel Number: 0H - FH (0 - 15) 0=ch.1 15=ch.16
kk=Note Number: 00H - 7FH (0 - 127)
vv=Velocity: 01H - 7FH (1 - 127)
* vv=00H is received as Note-off (velocity 40H).
●Control Change
❍
Bank Select
STATUS SECOND THIRD
BnH 00H mmH
n=MIDI Channel Number: 0H - FH (0 - 15) 0=ch.1 15=ch.16
mm=Bank Number: 00H, 01H
* The LSB of Bank Select is ignored.
* Can be received only through the Basic channel.
❍Modulation
STATUS SECOND THIRD
BnH 01H vvH
n=MIDI Channel Number: 0H - FH (0 - 15) 0=ch.1 15=ch.16
vv=Modulation Depth: 00H - 7FH (0 - 127)
* Can be received only through the Basic channel.
❍Foot Type
STATUS SECOND THIRD
BnH 04H vvH
n=MIDI Channel Number: 0H - FH (0 - 15) 0=ch.1 15=ch.16
vv=Control Value: 00H - 7FH (0 - 127)
* Can be received only through the Basic channel.
❍Volume
STATUS SECOND THIRD
BnH 07H vvH
n=MIDI Channel Number: 0H - FH (0 - 15) 0=ch.1 15=ch.16
vv=Volume: 00H - 7FH (0 - 127)
* Can be received only through the Basic channel.
❍Pan
STATUS SECOND THIRD
BnH 0AH vvH
n=MIDI Channel Number: 0H - FH (0 - 15) 0=ch.1 15=ch.16
vv=Pan: 00H - 40H - 7FH (0 - 64 - 127)
* Can be received only through the Basic channel.
* The value 0 is left, 64 is center, and 127 is right.You can adjust in 127 steps from 0 to 127.
❍General Purpose #2
STATUS SECOND THIRD
BnH 11H vvH
n=MIDI Channel Number: 0H - FH (0 - 15) 0=ch.1 15=ch.16
vv=Control Value: 00H - 7FH (0 - 127)
0: minor, -7th,
1: minor, -6th,
2: minor, -5th,
3: minor, -4th,
4: minor, -3rd,
5: minor, -2nd,
6: minor, +2nd,
7: minor, +3rd,
8: minor, +4th,
9: minor, +5th,
10: minor, +6th,
11: minor, +7th,
12: minor, Diminish,
64: major, -7th,
65: major, -6th,
66: major, -5th,
67: major, -4th,
68: major, -3rd,
69: major, -2nd,
70: major, +2nd,
71: major, +3rd,
72: major, +4th,
73: major, +5th,
74: major, +6th,
75: major, +7th,
76: major, Diminish,
* Can be received only through the Basic channel.
* Received when Harmony is on, to switch the key between Major/Minor.
❍General Purpose #3
STATUS SECOND THIRD
BnH 12H vvH
n=MIDI Channel Number: 0H - FH (0 - 15) 0=ch.1 15=ch.16
vv=Control Value: 00H - 7FH (0 - 127)
* Can be received only through the Basic channel when this channel is set to POLY1-
POLY16.
* When the Basic channel is set to MONO1-MONO11, reception takes place on the
channels for each string.
* When the PLAY FEEL is set to ENVELOPE1 or ENVELOPE2, and recognized as the
string envelope follow values.
❍General Purpose #4
STATUS SECOND THIRD
BnH 13H vvH
n=MIDI Channnel Number: 0H - FH (0 - 15) 0=ch.1 15=ch.16
vv=Control Value: 00H - 7FH (0 - 127) 00H = Reset,
01H-3FH=OFF, 40H-7FH=ON
* Can be received only through the Basic channel.
* Having received this message, the GR-33 acts as if the onboard WAH(foot switch) is
operated.
