GT-3 Feb. 1999
5
CRYSTAL, RESONATOR
00894023 MA-406 20MHZ TE24 CRYSTAL X1 on Main Board
01453167 SG-8002DC 67.7376MHZ CRYSTAL XT1 on Main Board
ENCODER
01013223 EVQ VEM F01 24B
POTENTIOMETER (ROTARY ENCODER)
EN1 on SW Board
CONNECTOR
# 13369916 5597-14APB CONNECTOR 14P CN2 on Main Board
# 01780123 5597-18APB CONNECTOR 18P CN3 on Main Board
# F3449702 6216 014 110 808 CONNECTOR 14P CN1 on SW Board
# F3439122 6216 018 110 808 CONNECTOR 18P CN4 on SW Board
# F3439123 A2001WR2-3P CONNECTOR 3P CN4 on Main Board
# F3439121 A2541WR2-2A16NP CONNECTOR 16P CN1 on Main Board
WIRING, CABLE
# F3479101 FFC CARD 14P L=80MM
BETWEEN MAIN BOARD ASSY AND SW BOARD 2 ASSY
# F3479102 FFC CARD 18P L=115MM
BETWEEN MAIN BOARD ASSY AND SW BOARD 1 ASSY
G3477140 RIBON CABLE 3P CN2,CN3 on SW Board
# G3467132 WIRING 16P L=230MM for LCD
# G3467133 WIRING 3P L=330MM CN5 on SW Board
BATTERY
12569249S0 CR2032
LITHIUM BATTERY 220MAH/3V
SCREWS
40016067 PLAIN WASHER 6X13X1 BZC for VR PEDAL ASSY
40011312 SCREW M3×8 BINDING P-TITE FE BZC for MIDI JACK
40011278 SCREW M3×8 BINDING P-TITE FE ZC for SW BOARD ASSY
40019123 SCREW M3×8 BINDING S-TIGHT BZC for SW PEDAL ASSY
# 40342701 SCREW M2.3×8 BINDING TAP TIGHT P ZC for LCD
40127689 SCREW M3×10
BINDING TAPTIGHT S TYPE FE BZC
for CORD HOOK
40012867 SCREW M3×8 PAN HEAD DOUBLE SEMS FE ZC for MAIN ESCUTCHEON, SW BOARD ASSY
40011878 M3 EXTERNAL TOOTH WASHER FECM for MAIN BOARD (near CN2)
40016445 NUT (JACK) HAJ-0999-01-190
# 40342690 HEX BOLT M6×85 HALF THREAD BZC for VR PEDAL ASSY
40016456 WASHER (JACK) HSJ-0999-01-210
40015901 E-RING M2.5 SUS for VR PEDAL ASSY
40016001 LOCK NUT M6 U BZC for VR PEDAL ASSY
# 40342712 SCREW M3×6
PAN MACHINE W/SW+SMALL PW BZC
for BOTTOM COVER
40012534 SCREW M3×6 BINDING S-TITE FE BZC
for BOTTOM COVER, ADAPTOR JACK HOLDER, VR PEDAL ASSY
40013067 SCREW M3×8 PAN SEMS FE ZC for MAIN BOARD
40123545 NUT M9×11×2 (JACK) FE NI
40016467 JACK WASHER M9.2×14×0.5 FE NI
PACKING
# G2267109 AC ADAPTOR PAD
# G2267108 LOWER PAD
# G2607210 PACKING CASE
# G2267107 UPPER PAD
MISCELLANEOUS
# G2147118 AC JACK HOLDER for JK1(ADAPTOR JACK) on Main Board
G2357108 BASE for BOTTOM COVER
12189815 BATTERY HOLDER BH-32 BT1 on Main Board
# G2147119 BOLT HOLDER for VR PEDAL ASSY
22360712 CORD HOOK 236-712 for AC ADAPTOR CORD
# G2357110 CUSHION F for VR PEDAL ASSY
# G2357111 CUSHION R for VR PEDAL ASSY
# G2567104 DISPLAY COVER LCD COVER
# G2257203 JACK COVER for JK9(INPUT JACK) on Main Board
# G2567103 MAIN ESCUTCHEON for PANEL SW,ENCODER,LCD
G2227301 PEDAL ESCUTCHEON for PEDAL SW ASSY
G2357109 PEDAL FOOT for PEDAL SW ASSY
# G2147115 PEDAL HOLDER for VR PEDAL ASSY
# G2217705 PEDAL LABEL(1) for PEDAL SW ASSY
# G2217706 PEDAL LABEL(2) for PEDAL SW ASSY
# G2217707 PEDAL LABEL(3) for PEDAL SW ASSY
# G2217708 PEDAL LABEL(4) for PEDAL SW ASSY
# G2217710 PEDAL LABEL(CTL) for PEDAL SW ASSY
# G2217709 PEDAL LABEL(DOWN) for PEDAL SW ASSY
# G2217711 PEDAL LABEL(UP) for PEDAL SW ASSY
# G2147117 PIN STAY for VR PEDAL ASSY
# G2147116 SHAFT STAY for VR PEDAL ASSY
# H2369401 SPACER 3*6*10 for LED1-LED5(L-34HDSL) on SW Board
G2177103 SUPPORT SPRING for PEDAL SW ASSY
G2187602 SWITCH PEDAL for PEDAL SW ASSY
# G2357112 VR PLATE for VR PEDAL ASSY
40016523 INSULOK TIE 100M/M T-18R <<ORDERING PER1000PCS>> for Main Board ASSY
ACCESSORIES (Standard)
00899078 AC ADAPTOR BRC-100
00899089 AC ADAPTOR BRC-120
00899090 AC ADAPTOR BRC-230
00899101 AC ADAPTOR BRC-240A
# G6017276 OWNER'S MANUAL ENGLISH
# G6017277 OWNER'S MANUAL JAPANESE
# G6017279 QUICK START ENGLISH
# G6017278 QUICK START JAPANESE
/クリスタル､発振子
/エンコーダー
/コネクター
/ワイヤリング,ケーブル
/電池
/ねじ類
/梱包材
/その他
/標準付属品
