12
Sync Operation with External Devices
You can sync the R-1000 to other devices. Set the following [SYNC] menu settings according to your sync setup. For details of
parameter setup, refer to “Menu Operations and Menu List” of the owner’s manual.
When you perform the sync operation, select [EXT.CLOCK with V-MIXER] or [EXT.CLOCK with D.SNAKE] in REAC SETUP.
CLOCK SOURCE
fig.clocksource-setup.eps
* If you select [WORD CLOCK] as CLOCK SOURCE, the sampling frequency of your current project must match the sampling frequency of your
external clock source.
TC SOURCE
fig.TCsource-setup.eps
If [SMPTE (LTC)] or [MIDI (MTC)] is selected as TC SOURCE, set the R-1000's frame rate to match the frame rate of your TC source. .
You can select from below.
fig.framerate.eps
Others
You can set parameters below in [TIMECODE] menu and [MIDI] menu.
fig.other-setup.eps
About sync settings of the R-1000
REAC
WORD CLOCK
VIDEO SYNC
Provides sync from the R-1000's internal clock.
Synchronises to the WORD CLOCK IN.
Generates sampling clock from the black burst that is input to VIDEO SYNC IN connector.
Value Operation
INTERNAL
SMPTE (LTC)
MIDI (MTC)
Generates timecode from the R-1000's internal clock.
Synchronises to SMPTE timecode coming in from SMPTE (LTC) IN connector.
Synchronises to MIDI timecode coming in from MIDI IN connector.
Value Operation
29.97D
29.97
25
30
24
29.97 fps (Drop Frame)
29.97 fps (Non-Drop Frame)
25 fps
30 fps
24 fps
OFF/ON
Max 23h59m59s29f
OFF, MASTER, SLAVE
Starts playback automatically at receipt of timecode if this is turned ON.
Offsets the R-1000's timecode.
Sets MIDI Machine Control mode.
Value Operation
Sends MIDI timecode if this is turned ON.OFF/ON
CHASE PLAY
OFFSET
MMC MODE
Parameter
MTC OUTPUT
To Next Page
