Roland RD-700NX Midi Implementation

11
MIDI Implementation
|# 00 4F | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 20 (12768 - 52768) |
| | | -20000 - +20000 |
|-------------+----------------------------------------------------------------|
| 00 00 00 53 | Total Size |
+------------------------------------------------------------------------------+
* Live Set MFX
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0000 000a | MFX Switch (0 - 1) |
|-------------+-----------+----------------------------------------------------|
|# 00 03 | 0000 aaaa | |
| | 0000 bbbb | MFX Type (0 - 255) |
|-------------+-----------+----------------------------------------------------|
|# 00 11 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 1 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 15 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 2 (12768 - 52768) |
| | | -20000 - +20000 |
| : | | |
|# 01 0D | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 32 (12768 - 52768) |
| | | -20000 - +20000 |
|-------------+----------------------------------------------------------------|
| 00 00 01 11 | Total Size |
+------------------------------------------------------------------------------+
* Live Set Resonance
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0000 000a | Resonance Switch (0 - 1) |
|-------------+-----------+----------------------------------------------------|
|# 00 11 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Resonance Parameter 1 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 15 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Resonance Parameter 2 (12768 - 52768) |
| | | -20000 - +20000 |
| : | | |
|# 01 0D | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Resonance Parameter 32 (12768 - 52768) |
| | | -20000 - +20000 |
|-------------+----------------------------------------------------------------|
| 00 00 01 11 | Total Size |
+------------------------------------------------------------------------------+
* Live Set Internal Layer
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0aaa aaaa | Layer Level (CC# 7) (0 - 127) |
| 00 01 | 0aaa aaaa | Layer Pan (CC# 10) (0 - 127) |
| | | L64 - 63R |
| 00 02 | 0aaa aaaa | Chorus Amount (0 - 127) |
| 00 03 | 0aaa aaaa | Reverb Amount (0 - 127) |
|-------------+-----------+----------------------------------------------------|
| 00 04 | 0aaa aaaa | Keyboard Range Lower (0 - 87) |
| | | A0 - UPPER |
| 00 05 | 0aaa aaaa | Keyboard Range Upper (0 - 87) |
| | | LOWER - C8 |
|-------------+-----------+----------------------------------------------------|
| 00 06 | 0aaa aaaa | Velocity Range Lower (1 - 127) |
| 00 07 | 0aaa aaaa | Velocity Range Upper (1 - 127) |
|-------------+-----------+----------------------------------------------------|
| 00 08 | 0aaa aaaa | Velocity Sensitivity (1 - 127) |
| | | -63 - +63 |
| 00 09 | 0aaa aaaa | Velocity Max (1 - 127) |
|-------------+-----------+----------------------------------------------------|
| 00 0A | 0aaa aaaa | keyboard Transpose (16 - 112) |
| | | -48 - +48 |
|-------------+-----------+----------------------------------------------------|
| 00 0B | 0000 000a | Layer Switch (0 - 1) |
| | | OFF, ON |
|-------------+-----------+----------------------------------------------------|
| 00 0C | 0000 000a | Receive Damper Switch (0 - 1) |
| | | OFF, ON |
| 00 0D | 0000 000a | Receive FC1 Switch (0 - 1) |
| | | OFF, ON |
| 00 0E | 0000 000a | Receive FC2 Switch (0 - 1) |
| | | OFF, ON |
| 00 0F | 0000 000a | Receive Modulation Switch (0 - 1) |
| | | OFF, ON |
| 00 10 | 0000 000a | Receive Bender Switch (0 - 1) |
| | | OFF, ON |
| 00 11 | 0000 000a | Receive Control Slider Switch (UPPER1) (0 - 1) |
| | | OFF, ON |
| 00 12 | 0000 000a | Receive Control Slider Switch (UPPER2) (0 - 1) |
| | | OFF, ON |
| 00 13 | 0000 000a | Receive Control Slider Switch (LOWER1) (0 - 1) |
| | | OFF, ON |
| 00 14 | 0000 000a | Receive Control Slider Switch (LOWER2) (0 - 1) |
| | | OFF, ON |
| 00 15 | 0000 000a | Receive S1 Switch (0 - 1) |
| | | OFF, ON |
| 00 16 | 0000 000a | Receive S2 Switch (0 - 1) |
| | | OFF, ON |
|-------------+-----------+----------------------------------------------------|
| 00 17 | 0000 000a | Receive Bank Select Switch (0 - 1) |
| | | OFF, ON |
| 00 18 | 0000 000a | Receive Program Change Switch (0 - 1) |
| | | OFF, ON |
| 00 19 | 0000 000a | Receive Bender Switch (0 - 1) |
| | | OFF, ON |
| 00 1A | 0000 000a | Receive Modulation Switch (0 - 1) |
| | | OFF, ON |
| 00 1B | 0000 000a | Receive Volume Switch (0 - 1) |
| | | OFF, ON |
| 00 1C | 0000 000a | Receive Pan Switch (0 - 1) |
| | | OFF, ON |
| 00 1D | 0000 000a | Receive Hold-1 Switch (0 - 1) |
| | | OFF, ON |
| 00 1E | 0000 000a | Receive Expression (0 - 1) |
| | | OFF, ON |
|-------------+-----------+----------------------------------------------------|
| 00 00 00 1F | Total Size |
+------------------------------------------------------------------------------+
* Live Set External Layer
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0aaa aaaa | Keyboard Range Lower (0 - 87) |
| | | A0 - UPPER |
| 00 01 | 0aaa aaaa | Keyboard Range Upper (0 - 87) |
| | | LOWER - C8 |
|-------------+-----------+----------------------------------------------------|
| 00 02 | 0aaa aaaa | Velocity Range Lower (1 - 127) |
| | | |
| 00 03 | 0aaa aaaa | Velocity Range Upper (1 - 127) |
| | | |
|-------------+-----------+----------------------------------------------------|
| 00 04 | 0aaa aaaa | Velocity Sensitivity (1 - 127) |
| | | -63 - +63 |
| 00 05 | 0aaa aaaa | Velocity Max (1 - 127) |
|-------------+-----------+----------------------------------------------------|
| 00 06 | 0aaa aaaa | keyboard Transpose (16 - 112) |
| | | -48 - +48 |
|-------------+-----------+----------------------------------------------------|
| 00 07 | 0000 000a | Layer Switch (0 - 1) |
| | | OFF, ON |
|-------------+-----------+----------------------------------------------------|
| 00 08 | 0000 000a | Damper Switch (0 - 1) |
| | | OFF, ON |
| 00 09 | 0000 000a | FC1 Switch (0 - 1) |
| | | OFF, ON |
| 00 0A | 0000 000a | FC2 Switch (0 - 1) |
| | | OFF, ON |
| 00 0B | 0000 000a | Modulation Switch (0 - 1) |
| | | OFF, ON |
| 00 0C | 0000 000a | Bender Switch (0 - 1) |
| | | OFF, ON |
| 00 0D | 0000 000a | Control Switch (MFX) (0 - 1) |
| | | OFF, ON |
| 00 0E | 0000 000a | Control Slider Switch (UPPER1) (0 - 1) |
| | | OFF, ON |
| 00 0F | 0000 000a | Control Slider Switch (UPPER2) (0 - 1) |
| | | OFF, ON |
| 00 10 | 0000 000a | Control Slider Switch (LOWER1) (0 - 1) |
| | | OFF, ON |
| 00 11 | 0000 000a | Control Slider Switch (LOWER2) (0 - 1) |
| | | OFF, ON |
| 00 12 | 0000 0aaa | Transmit Port (0 - 4) |
| | | ALL, OUT1, OUT2, OUT3, USB |
|-------------+-----------+----------------------------------------------------|
| 00 13 | 0000 aaaa | Transmit Channel (0 - 15) |
| | | 1 - 16 |
| 00 14 | 0000 000a | Transmit Bank Select MSB Switch (0 - 1) |
| | | OFF, ON |
| 00 15 | 0aaa aaaa | Transmit Bank Select MSB (CC# 0) (0 - 127) |
| 00 16 | 0000 000a | Transmit Bank Select LSB Switch (0 - 1) |
| | | OFF, ON |
| 00 17 | 0aaa aaaa | Transmit Bank Select LSB (CC# 32) (0 - 127) |
| 00 18 | 0000 000a | Transmit Program Change Switch (0 - 1) |
| | | OFF, ON |
| 00 19 | 0aaa aaaa | Transmit Program Change# (0 - 127) |
|-------------+-----------+----------------------------------------------------|
| 00 1A | 0000 000a | Transmit Level Switch (0 - 1) |
| | | OFF, ON |
| 00 1B | 0aaa aaaa | Transmit Level (CC# 7) (0 - 127) |
|-------------+-----------+----------------------------------------------------|
| 00 1C | 0000 000a | Transmit Pan Switch (0 - 1) |
| | | OFF, ON |
| 00 1D | 0aaa aaaa | Transmit Pan(CC# 10) (0 - 127) |
| | | L64 - R63 |
|-------------+-----------+----------------------------------------------------|
| 00 1E | 0000 000a | Transmit Coarse Tune Switch (0 - 1) |
| | | OFF, ON |
| 00 1F | 0aaa aaaa | Transmit Coarse Tune (16 - 112) |
| | | -48 - +48 |
|-------------+-----------+----------------------------------------------------|
| 00 20 | 0000 000a | Transmit Fine Tune Switch (0 - 1) |
| | | OFF, ON |
| 00 21 | 0aaa aaaa | Transmit Fine Tune (14 - 114) |
| | | -50 - +50 |
|-------------+-----------+----------------------------------------------------|
| 00 22 | 0000 000a | Transmit Mono/Poly Switch (0 - 1) |
| | | OFF, ON |
| 00 23 | 0000 00aa | Transmit Mono/Poly (0 - 1) |
| | | MONO, POLY |
|-------------+-----------+----------------------------------------------------|
| 00 24 | 0000 000a | Transmit Portamento Switch (0 - 1) |
| | | OFF, ON |
| 00 25 | 0000 000a | Transmit Portamento Switch Value (0 - 1) |
| | | OFF, ON |
|-------------+-----------+----------------------------------------------------|
| 00 26 | 0000 000a | Transmit Portamento Time Switch (0 - 1) |
| | | OFF, ON |
| 00 27 | 0aaa aaaa | Transmit Portamento Time (0 - 127) |
|-------------+-----------+----------------------------------------------------|
| 00 28 | 0000 000a | Transmit Cutoff Switch (0 - 1) |
| | | OFF, ON |
| 00 29 | 0aaa aaaa | Transmit Cutoff (0 - 127) |
| | | -64 - +63 |
|-------------+-----------+----------------------------------------------------|
| 00 2A | 0000 000a | Transmit Resonance Switch (0 - 1) |
| | | OFF, ON |
| 00 2B | 0aaa aaaa | Transmit Resonance (0 - 127) |
| | | -64 - +63 |
|-------------+-----------+----------------------------------------------------|
| 00 2C | 0000 000a | Transmit Attack Time Switch (0 - 1) |
| | | OFF, ON |
| 00 2D | 0aaa aaaa | Transmit Attack Time (0 - 127) |
| | | -64 - +63 |
|-------------+-----------+----------------------------------------------------|
| 00 2E | 0000 000a | Transmit Decay Time Switch (0 - 1) |
| | | OFF, ON |
| 00 2F | 0aaa aaaa | Transmit Decay Time (0 - 127) |
| | | -64 - +63 |
|-------------+-----------+----------------------------------------------------|
| 00 30 | 0000 000a | Transmit Release Time Switch (0 - 1) |
| | | OFF, ON |
| 00 31 | 0aaa aaaa | Transmit Release Time (0 - 127) |
| | | -64 - +63 |
|-------------+-----------+----------------------------------------------------|
| 00 32 | 0000 000a | Transmit Pitch Bend Range Switch (0 - 1) |
| | | OFF, ON |
| 00 33 | 00aa aaaa | Transmit Pitch Bend Range (0 - 48) |
|-------------+-----------+----------------------------------------------------|
| 00 34 | 0000 000a | Transmit Modulation Depth Switch (0 - 1) |
| | | OFF, ON |
| 00 35 | 0aaa aaaa | Transmit Modulation Depth (0 - 127) |
| | | 0 - 100 Cent |
|-------------+-----------+----------------------------------------------------|
| 00 36 | 0000 000a | Transmit Chorus Level Switch (0 - 1) |
| | | OFF, ON |
| 00 37 | 0aaa aaaa | Transmit Chorus Level (0 - 127) |
|-------------+-----------+----------------------------------------------------|
| 00 38 | 0000 000a | Transmit Reverb Level Switch (0 - 1) |
| | | OFF, ON |
| 00 39 | 0aaa aaaa | Transmit Reverb Level (0 - 127) |
|-------------+-----------+----------------------------------------------------|
| 00 3A | 0000 000a | Transmit Control Change 1 Switch (0 - 1) |
| | | OFF, ON |
| 00 3B | 0aaa aaaa | Transmit Control Change 1 Number (0 - 127) |

Roland RD-700NX Specifications

Power

power consumption	12 W

Audio and Sound

maximum polyphony	128 voices
sound generator	SuperNATURAL Piano, SuperNATURAL (E.Piano), Virtual Tone Wheel Organ, PCM Sound Generator, GM2 (for SMF Playback)
effects	Multi-Effects (2 x 4 systems, 84 types), Reverb (6 types), Chorus (3 types), 3-band Compressor, 4-band Digital Equalizer

Connectivity

output jacks	L/MONO, R Jacks (1/4-inch phone type), BALANCED OUT (L, R) Jacks (XLR type)
pedal jacks	DAMPER Pedal Jack, Control Pedal Jacks (FC1, FC2)
midi connectors	IN, OUT1, OUT2, THRU/OUT3

Weight and Dimensions

width	1, 444 mm (56-7/8 inches)
depth	375 mm (14-13/16 inches)
height	148 mm (5-7/8 inches)
weight	25.0 kg (55 lbs 2 oz)
