10
Sep. 2009 SP-404SX
Parts List
fig.-part1-e.eps
Due to one or more of the following reasons,
parts with parts code ******** cannot be supplied as service parts.
• Part supplied only as a component in a complete assembly
• Copyright does not permit the part to be supplied
• Part is sold commercially
Note: The parts marked # are new. (initial parts) The description “Q’ty” means a necessary number of the parts per one product.
Safety Precautions:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
CASING
# 5100006870 TOP CASE 1
# 5100006876 TOP PANEL 1
# 5100006877 REAR PANEL 1
03908945 BOTTOM CASE 1
04679101 DISPLAY COVER 1
# 5100006873 SD COVER 1
03908901 BATTERY COVER 1
CHASSIS
03908978 PWB HOLDER MAIN 1
# 5100009219 SHIELD PLATE 1
KNOB, BUTTON
03565234 J R-KNOB SF-ELA BLK/SLV 4
# 5100008495 RUBBER SW EFFECT 1
# 5100006879 RUBBER SW PAD 1
SWITCH
02671312 SLIDE SWITCH SLG-22-465 1
JACK, EXT TERMINAL
01566445 DIN CONNECTOR YKF51-5067 1
01899801 RCA (PIN) JACK YKC21-3834N 2
13449275 6.5MM JACK YKB21-5074 2
13449711 AC ADAPTOR JACK HEC0470-01-630 1
PWB ASSY
# 5100007184 MAIN BOARD ASSY 1
# 5100007188 PANEL SHEET ASSY 1
* This unit includes the following parts.
# ******** PANEL BOARD 1
# ******** JACK BOARD 1
DIODE
01904112 LED (RED) SLR-342VCT32 N.P.Q RANK 1
04676401 LED BA56-11EWA 1
POTENTIOMETER
03679256 ROTARY POTENTIOMETER RK09D1130C5B 3
13279884 POTENTIOMETER RK09K1110A0J 10KB 1
04011745 ROTARY POTENTIOMETER RK09K12C0A8H 1
WIRING, CABLE
# 5100009117 WIRING W1 1
02343223 WIRING 6X100-P2.0-PHR-PHR-F 1
02344012 WIRING 12X150-P2.0-PHR-PHR-F 1
# 5100008919 BAN CARD 20624 FWR-P=1.00-K1-18-100 1
# 5100008922 BAN CARD 20624 FWR-P=1.00-K1-22-100 1
SCREWS
40011490 SCREW M3X6 PAN MACHINE W/SW BZC 1
40230590 SCREW M3X10 BINDING MACHINE NI 1
02126156 SCREW M3X10 HEX SOCKET HEAD CAP TAPTITE P 4
40011312 SCREW 3X8 BINDING TAPTITE P FE BZC 12
40011112 SCREW 3X10 BINDING TAPTITE B BZC 2
To Next Page
