Roland SP-404SX Service Notes

7
Sep. 2009 SP-404SX
Exploded View Parts List
* When ordering No. 13, order No. 21 as well.
No. Part Code Part Name Description Q’ty
1 5100006876 TOP PANEL 1
2 03565234 J R-KNOB SF-ELA BLK/SLV 4
3 5100006870 TOP CASE 1
4 5100006873 SD COVER 1
5 04679101 DISPLAY COVER 1
6 5100008495 RUBBER SW EFFECT 1
5100007188 PANEL SHEET ASSY 1
* This unit includes the following parts.
7 ******** PANEL BOARD 1
15 ******** JACK BOARD 1
8 5100006879 RUBBER SW PAD 1
9 03908978 PWB HOLDER MAIN 1
10 5100007184 MAIN BOARD ASSY 1
11 5100009219 SHIELD PLATE 1
12 03908945 BOTTOM CASE 1
13 03908901 BATTERY COVER 1
14 5100006877 REAR PANEL 1
16 5100006883 BATTERY TERMINAL - 1
17 5100006884 BATTERY TERMINAL +- 1
18 03908912 BATTERY TERMINAL + 1
19 5100006885 BATTERY TERMINAL PM 1
20 00340690 FOOT ZULEN (CUSHION) XCK040 12MM 4
21 40672389 BATTERY CUSHION 2

Roland SP-404SX Specifications

General

Display type	LED
Built-in display	Yes
Display number of characters	3
Bit rate	16 bit
Sample rate	44.1 kHz
Number of pads	13
Number of samples	120
Maximum polyphony (notes)	12
Battery type	AA
Battery voltage	9 V
Power source type	AC, Battery
Number of batteries supported	6
Compatible memory cards	SD
Included memory card size	1 GB

Weight and Dimensions

Depth	257 mm
Width	178 mm
Height	72 mm
Weight	1200 g
