38. Press [ ] and select DecB-Inp1 [C] or INPUT SELECT B1.
39. Input video to INPUT 1.
40. Verify that the picture that is input is displayed on the television monitor
connected to the OUTPUT jack.
41. Press [ ] and select DecB-Inp2 [C] or INPUT SELECT B2.
42. Input video to INPUT 2.
43. Verify that the picture that is input is displayed on the television monitor
connected to the OUTPUT jack.
44. Press [ ] and select DecB-Inp3 [C] or INPUT SELECT B3.
45. Input video to INPUT 3.
46. Verify that the picture that is input is displayed on the television monitor
connected to the OUTPUT jack.
47. Press [ ] and select DecB-Inp4 [C] or INPUT SELECT B4.
48. Input video to INPUT 4.
49. Verify that the picture that is input is displayed on the television monitor
connected to the OUTPUT jack.
Thereafter, for INPUT 5 through INPUT 7, verify picture display at both the
INPUT S-VIDEO jack and the INPUT jack.
50. Press [ ] and select DecB-Inp5 [S/C] or INPUT SELECT B5.
51. Input video to INPUT S-VIDEO 5.
52. Verify that the picture that is input is displayed on the television monitor
connected to the OUTPUT jack.
53. Disconnect the S-connector cable connected to INPUT S-VIDEO 5.
54. Input video to INPUT 5.
55. Verify that the picture that is input is displayed on the television monitor
connected to the OUTPUT jack.
56. Press [ ] and select DecB-Inp6 [S/C] or
INPUT SELECT B6.
57. Input video to INPUT S-VIDEO 6.
58. Verify that the picture that is input is displayed on the television monitor
connected to the OUTPUT jack.
59. Disconnect the S-connector cable connected to INPUT S-VIDEO 6.
60. Input video to INPUT 6.
61. Verify that the picture that is input is displayed on the television monitor
connected to the OUTPUT jack.
62. Press [ ] and select DecB-Inp7 [S/C] or INPUT SELECT B7.
63. Input video to INPUT S-VIDEO 7.
64. Verify that the picture that is input is displayed on the television monitor
connected to the OUTPUT jack.
65. Disconnect the S-connector cable connected to INPUT S-VIDEO.
66. Input video to INPUT 7.
67. Verify that the picture that is input is displayed on the television monitor
connected to the OUTPUT jack.
68. Press [ ] and select DecB-Inp8 [PC2/S] or INPUT SELECT B8.
69. Input video to INPUT S-VIDEO 8.
70. Verify that the picture that is input is displayed on the television monitor
connected to the OUTPUT jack.
71. Disconnect the S-connector cable connected to INPUT S-VIDEO 8.
72. Input video to PC2.
73. Verify that the picture that is input is displayed on the television monitor
connected to the OUTPUT jack.
74. Hold down the [MENU] button and press the [ENTER] button.
IN-OUT TEST OK is displayed, “IN/OUT TEST” ends, and the Test
Mode menu screen appears. Move the cursor to the [FPGA LOAD] item.
11: FPGA LOAD
1. At the Test Mode menu screen, select FPGA LOAD, then press the
[ENTER] button.
The test is executed the moment the [ENTER] button is pressed.
* During the test, the picture output from the V-8 is a black screen.
After a short while, the test ends and OK is displayed.
2. Hold down the [MENU] button and press the [ENTER] button.
FPGA LOAD OK is displayed, “FPGA LOAD TEST” ends, and the Test
Mode menu screen is displayed again.
